Disassembly and Reassembly
Samsung Electronics4-53
No Parts Procedure Remark
9) Remove the screw what is fix with Base
Part and Drain Pan. (upper side:2EA)
10) Remove the screw what is fix with Base
Part and Drain Pan. (lower side:2EA)
11) Remove the Drain Pan completely.
24103A(1)_1 12/23/05 12:01 PM Page 3-62
To Next Page
