Exploded Views and Parts List
Loc. No Parts No. Description ; Specification Q ty SNA Remark
A001 AK59-00070B REMOCON-ASSY;BD-P1400/XER,SEC,240 1 SA
C001 AK97-02081D ASSY-PANEL FRONT;ABS HB,BD-P1400/ 1 SA
C015 AK63-00313C COVER-TOP;BD-P1200,PCM,T0.7,W430, 1 SA
H003 AK97-02140A ASSY-BDP LOADER N;-,BD-P1400-SEC4 1 SA
M210 AK81-00006B WASHER-HEX;SWCH18A,7,12,2.5,BLK,- 2 SA
P001 AK92-01515A ASSY PCB-MAIN;BD-P1400/XEU,ASSY M 1 SA
P003 AK92-01516A ASSY PCB-SMPS;BD-P1400/XEU,ASSY S 1 SA
P007F AK92-01498B ASSY PCB-FRONT KEY;BD-P1400/XEL,A 1 SA
P007P AK92-01507A ASSY PCB-POWER KEY;BD-P1400,ASSY 1 SA
P025 AC39-10019A CBF-POWER CORD;KKP-419C,H03VVH2-F 1 SA
P030 3103-001158 FAN-DC;12V,20mA,2000rpm,0.125m^3/ 1 SA
W001 6003-000275 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC 8 SA
W009 6003-000276 SCREW-TAPTITE;BH,+,-,B,M3,L10,ZPC 13 SA
W271 6009-001411 SCREW-SPECIAL;TH,+,-,M5,L14,NI PL 2 SA
W344 6003-001076 SCREW-TAPTITE;BH,+,-,S,M3,L6,ZPC( 1 SA
W348 6003-000255 SCREW-TAPTITE;BWH,+,-,B,M3,L8,ZPC 7 SA
AK64-02105A
AK61-00519A
C002
C011
DOOR-TRAY;BD-P1400,ABS 94HB,T2,H20
SPRING ETC-DOOR;DVD-SR420,STS304WP
1 SA
1 SA
