33.. CCapacityapacity T Tablablee
(1) CNH18HDB (AC018BNHDCH/AA) + CXC18SCB (AC018BXSCCC/AA)
Cooling
TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input
NOTE
• The performance table shows the average value of each conditions.
Duct S
(2) CNH24HDB (AC024BNHDCH/AA) + CXC24SCB (AC024BXSCCC/AA)
Cooling
TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW
-40 23.1 16.7
1.44
24.3 17.2
1.47
25.3 17.7
1.50
26.1 18.3
1.53
26.6 18.1
1.55
28.0 17.9
1.56
29.4 17.5
1.59
0 19.9 14.4
1.60
21.0 14.8
1.63
21.8 15.3
1.67
22.5 15.8
1.70
23.0 15.6
1.72
24.1 15.4
1.73
25.3 15.1
1.77
70 21.5 15.5
1.76
22.6 16.0
1.80
23.6 16.5
1.83
24.3 17.0
1.87
24.8 16.8
1.89
26.0 16.7
1.91
27.3 16.3
1.95
95 15.9 11.5
1.60
16.8 11.9
1.63
17.5 12.2
1.67
18.0 12.6
1.70
18.4 12.5
1.72
19.3 12.3
1.73
20.2 12.1
1.77
115 16.7 13.8
2.40
17.6 14.2
2.45
18.3 14.7
2.50
18.9 15.1
2.55
19.3 15.0
2.58
20.2 14.8
2.60
21.3 14.5
2.65
122 11.9 11.1
1.84
12.6 11.4
1.88
13.1 11.8
1.92
13.5 12.2
1.96
13.8 12.0
1.97
14.5 11.9
1.99
15.2 11.7
2.03
80 / 67 82 / 70 86 / 72 90 / 75
Outdoor
Temp.
(℉, DB)
Indoor Temperature (℉, DB / WB)
68 / 57 72 / 61 77 / 64
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW
-40 25.5 19.7
1.77
26.8 20.3
1.81
27.9 21.0
1.84
28.8 21.6
1.88
29.4 21.4
1.90
30.8 21.2
1.92
32.4 20.7
1.96
0 23.4 18.1
1.55
24.6 18.6
1.58
25.6 19.2
1.61
26.4 19.8
1.65
26.9 19.6
1.66
28.3 19.4
1.68
29.7 19.0
1.71
70 28.7 22.2
2.10
30.2 22.9
2.14
31.4 23.6
2.19
32.4 24.3
2.23
33.0 24.1
2.25
34.7 23.8
2.28
36.4 23.3
2.32
95 21.2 15.3
2.21
22.3 15.8
2.26
23.3 16.3
2.30
24.0 16.8
2.35
24.5 16.6
2.37
25.7 16.5
2.40
27.0 16.1
2.44
115 20.2 16.6
2.88
21.2 17.2
2.93
22.1 17.7
2.99
22.8 18.2
3.06
23.3 18.1
3.09
24.4 17.9
3.12
25.6 17.5
3.18
122 18.0 15.8
2.76
19.0 16.3
2.82
19.8 16.8
2.88
20.4 17.3
2.94
20.8 17.2
2.97
21.8 17.0
3.00
22.9 16.7
3.06
Outdoor
Temp.
(℉, DB)
Indoor Temperature (℉, DB / WB)
68 / 57 72 / 61 77 / 64 80 / 67 82 / 70 86 / 72 90 / 75
To Next Page
