3. Capacity Table
Wall Mounted Type
(3) CNH30TDB(AC030BNTDCH/AA)+CXC30SCB(AC030BXSCCC/AA)
Cooling
(4) CNH36TDB(AC036BNTDCH/AA)+CXC36SCB(AC036BXSCCC/AA)
Cooling
NOTE
• The performance table shows the average value of each conditions.
TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input
TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW
-40 29.2 22.6 3.04 30.7 23.3 3.11 32.0 24.0 3.17 33.0 24.8 3.23 33.7 24.5 3.27 35.3 24.3 3.30 37.1 23.8 3.36
0 30.5 23.6 3.04 32.1 24.3 3.11 33.5 25.1 3.17 34.5 25.9 3.23 35.2 25.6 3.27 36.9 25.4 3.30 38.8
24.9 3.36
70 31.8 24.6 2.63 33.5 25.4 2.68 34.9 26.2 2.74 36.0 27.0 2.79 36.7 26.7 2.82 38.6 26.5 2.85 40.5 25.9 2.91
95 26.5 20.5 2.77 27.9 21.2 2.82 29.1 21.8 2.88 30.0 22.5 2.94 30.6 22.3 2.97 32.1 22.1 3.00 33.7 21.6 3.06
115 19.9 18.5 3.04 21.0 19.1 3.11 21.8 19.6 3.17 22.5 20.3 3.23 23.0 20.0 3.27 24.1 19.8 3.30 25.3 19.5 3.36
122 18.6 17.2 2.91 19.6 17.8 2.96 20.4 18.3 3.03 21.0 18.9 3.09 21.4 18.7 3.12 22.5 18.5 3.15
23.6 18.2 3.21
Outdoor
Temp.
(℉, DB)
Indoor Temperature (℉, DB / WB)
68 / 57 72 / 61 77 / 64 80 / 67 82 / 70 86 / 72 90 / 75
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW
-40 35.0 27.1 4.60 36.9 27.9 4.69 38.4 28.8 4.79 39.6 29.7 4.88 40.4 29.4 4.93 42.4 29.1 4.98 44.5 28.5 5.08
0 36.6 28.3 4.60 38.6 29.2 4.69 40.2 30.1 4.79 41.4 31.1 4.88 42.2 30.7 4.93 44.3 30.4 4.98 46.6 29.8 5.08
70 38.2 29.6 3.97 40.2 30.5 4.05 41.9 31.4 4.13 43.2 32.4 4.22 44.1 32.1 4.26 46.3 31.8 4.30 48.6 31.1 4.39
95 31.8 24.6 4.18 33.5 25.4 4.26 34.9 26.2 4.35 36.0 27.0 4.44 36.7 26.7 4.48 38.6 26.5 4.53 40.5 25.9 4.62
115 23.9 22.2 4.60 25.1 22.9 4.69 26.2 23.6 4.79 27.0 24.3 4.88 27.5 24.1 4.93 28.9 23.8 4.98 30.4 23.3 5.08
122 22.3 20.7 4.39 23.5 21.3 4.48 24.4 22.0 4.57 25.2 22.7 4.66 25.7 22.5 4.71 27.0 22.2 4.76 28.3 21.8 4.85
Outdoor
Temp.
(℉, DB)
Indoor Temperature (℉, DB / WB)
68 / 57 72 / 61 77 / 64 80 / 67 82 / 70 86 / 72 90 / 75
To Next Page
