3.DisassemblyandReassembly
DescriptionDescriptionPhoto
4.Unfasten4screwsontheAssyCover-Jack.
:M4X16BLKHEX
5.SeparateAssyCover-JackfromCover-Body.
*BeCarefulseparatetheconnectedAntennafromCover-Body.
6.Unfasten3screwsontheBracket-VT.
:M3X8BLK
Copyright©1995-2012SAMSUNG.Allrightsreserved.3-2
