3.DisassemblyandReassembly
DescriptionDescriptionPhoto
7.Unfasten2screwsonthePCB-VT.
:M3X6SLK
8.Unfasten3screwsontheHolder-Docksealandremovethe
solidiedbond.
:M3X8BLK
Andthen,separateAssyDockingfromCover-Body.
9.SeparateWooferfromCover-Body,unfasten3screwsonthe
Holder-Buttonsealandremovethesolidiedbond.
:M3X8BLK
