50 _ Exploded views and Parts list
MODEL CODE: DV5471AEP/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Drawing
No.
Code No. Description Specication QTY Un SA/SNA
2-2-2 6002-001149 SCREW-TAPPING TH,+,NO,2S,M4,L12,NIPLT,SWRCH18A 4 PC SNA
2-2-2 6002-001149 SCREW-TAPPING TH,+,NO,2S,M4,L12,NIPLT,SWRCH18A 1 PC SNA
2-2-2 6002-001149 SCREW-TAPPING TH,+,NO,2S,M4,L12,NIPLT,SWRCH18A 2 PC SNA
2-2-3 DC61-03045A BRACKET-HINGE(R) ORCA-DRYER,HGI-
SGHC,T1.4,L300,NTR,DV5471AEP/XAA
1 PC SA
2-2-4 DC61-03046A BRACKET-FRAME FRONT ORCA-DRYER,GI-
SGCC,T1.4,W400,NTR,DV5471AEP/
XAA
1 PC SNA
2-2-5 DC61-03133A GUIDE-COVERTOP DV5471AEP,PA,L10.0,ZytelFR50,BLK 4 PC SA
2-2-6 DC61-03135A BRACKET-HINGE(L) DV5471AEP,HGI-SGHC,T1.4,L300,NTR 1 PC SA
2-2-7 DC61-03169A BASE DV5471AEP,ABS,W682.0,H31.2,BLK 1 PC SNA
2-2-8 DC61-03174A FIXER-COVERTOP DV5471AEP/XAA,SK5,T0.8,W19.0,H21.
9,NTR,ORCA-PJT
2 PC SA
2-2-9 DC64-00828B DOOR-S/W SPE110F-1D3,NYLON,T13.6,H44,W44.3
,WHT,125/250V/10A
1 PC SA
2-2-10 DC97-07510B ASSYHOLDERLEVER -,MDE7800AYW,DRYER/DOOR
LOCK,-,-,-
1 PC SA
2-2-11 DC97-16737A ASSY FRAME FRONT(S) ORCA-DRYER,DV5471AEP/
XAA,EGI,T0.8,INOX
1 PC SA
2-2-12 6002-001436 SCREW-TAPPING PH,+,2,M4,L18,ZPC(WHT),SWRCH18A 2 PC SNA
2-2-12 6002-001436 SCREW-TAPPING PH,+,2,M4,L18,ZPC(WHT),SWRCH18A 2 PC SNA
