Samsung DV448AEP - Model code: DV5471 AEW;XAA

Exploded views and Parts list _ 51
MODEL CODE: DV5471AEW/XAA
Service Bom (SA:SERVICEAVAILABLE,SNA:SERVICENOTAVAILABLE)
Drawing
No.
Code No. Description Specication QTY Un SA/SNA
0 ASSY FRAME FRONT & DOOR ORCA-DRYER 1
1 DC97-16794A ASSY DOOR ORCA,DV5471AEW/XAA 1 PC SNA
1-1 6001-001773 SCREW-MACHINE TH,+,-,M5,L12,PASS,STS430,-,SEAL-
LOCK
2 PC SA
1-2 DC97-16735B ASSY DOOR ORCA,DV5471AEW/
XAA,L536.1*W548.1,WHITE
1 PC SA
1-2-1 6002-000213 SCREW-TAPPING TH,+,-
,1,M4,L12,ZPC(WHT),SWRCH18A,-
8 PC SNA
1-2-2 6002-000241 SCREW-TAPPING TH,+,-
,2S,M5,L12,ZPC(WHT),SWRCH18A,-
1 PC SA
1-2-3 6002-000444 SCREW-TAPPING TH,+,2,M4,L14,PASS,STS430 15 PC SA
1-2-3 6002-000444 SCREW-TAPPING TH,+,2,M4,L14,PASS,STS430 2 PC SA
1-2-4 6002-000445 SCREW-TAPPING TH,+,2,M4,L18,PASS,STS304 2 PC SA
1-2-5 DC61-00891A GUIDE-HINGE HAUZEN(DOM),POM,-,-,-,WHT,HINGE 4 PC SA
1-2-6 DC61-03053B GUIDE-HOLDERGLASS DV5471AEW/
XAA,ABS,W44.4,L21.9,H23.6
2 PC SNA
1-2-7 DC61-03054A HOLDER-GLASS DV5471AEP,PP,T3.0,GRAY 1 PC SA
1-2-8 DC61-03055A SUPPORT-HINGE DV5471AEP,GI-
SGCC,T1.4,L97.8,NTR,ORCA-PJT
2 PC SNA
1-2-9 DC61-03136A HINGE-DOOR DV5471AEP,ALDC,T2.5,W32.0,L210.0,
GRAY
1 PC SNA
1-2-10 DC62-00320A SEAL-AIR DV5471AEP,TPE,GRAY,W450.8,L424.0
,5045N
1 PC SA
1-2-11 DC63-00613B CUSHION-COVER(F) SEW-6HR129AT,SILICON,-,-,-,-,GRY 2 PC SA
1-2-12 DC63-01326B COVER-DOOR DV5471AEW/
XAA,ABS,T3.0,W548.2,L489.7,NEAT
WHITE
1 PC SA
1-2-13 DC63-01327B COVER-DOOR(I) DV5417AEW/
XAA,ABS,W480.9,L371.2,NEATWHT
1 PC SNA
1-2-14 DC63-01362A COVER-HINGE DV5471AEP,PET,T0.188,W34.0,L212.0
,NTR
1 PC SNA
1-2-15 DC63-01396A CUSHION-COVER(F) DV5471AEP/XAA,SILICON,GRAY 1 PC SNA
1-2-16 DC64-02616A DECORATION-DOOR DV5471AEP,ABS,T3.0,NTR,SPRAY(IN
OX)
1 PC SNA
1-2-17 DC64-02617A DOOR-SAFETY DV5471AEP,PET,T2.8,W484.7,L375.7,N
TR,ORCA
1 PC SNA
1-2-18 DC64-02705A DOOR-GLASS ORCA-DRYER,Tempered
GLASS,T3.2,W389.0xL302.6
1 PC SA
1-2-19 DC64-02706B HANDLE-DOOR DV5471AEW/
XAA,ABS,T3.0,W495.3,NEATWHITE
1 PC SA
1-2-20 DC66-00691A LEVER-DOOR DV5471AEP,POM,L52.0,F20-03,NTR 1 PC SNA
2 DC97-16791A ASSY FRAME FRONT ORCA-DRYER,DV5471AEW/XAA 1 PC SNA
2-1 DC97-14006B ASSY SCREW DV337,-,6002-000231+WASHER,-
,M4xL12(O.D11.8),NORUBBER
4 PC SA
2-2 DC97-16744C ASSY FRAME FRONT ORCA,DV5471AEW/XAA,EGI,T0.8,NEAT
WHITE
1 PC SA
2-2-1 6001-001773 SCREW-MACHINE TH,+,-,M5,L12,PASS,STS430,-,SEAL-
LOCK
2 PC SA
2-2-2 6002-001149 SCREW-TAPPING TH,+,NO,2S,M4,L12,NIPLT,SWRCH18A 4 PC SNA
2-2-2 6002-001149 SCREW-TAPPING TH,+,NO,2S,M4,L12,NIPLT,SWRCH18A 1 PC SNA
