Samsung DVD-E360 - Schematic Diagrams

6.SchematicDiagrams
6.SchematicDiagrams
NOTE
•ForschematicDiagram
-Resistorsareinohms,1/8Wunlessotherwisenoted.
NOTE
Donotusethepartnumbershownonthisdrawingforordering.Thecorrectpartnumberisshowninthepartslist(maybeslightlydifferentoramendedsincethisdrawingwasprepared).
CAUTION
Mostsemiconductordevicesareelectrostaticallysensitiveandthereforerequirethespecialhandlingtechniquesdescribedunderthe“electrostaticallysensitive(ES)devices”sectionofthisservicemanual.
WARNING
Componentsidentiedwiththemarkhavethespecialcharacteristicsforsafety.Whenreplacinganyofthesecomponents.Useonlythesametype.
Copyright©1995-2011SAMSUNG.Allrightsreserved.6-1
