Panoramic
NOTE:
X
Panoramic is an optional feature of this product.
X
This feature only works with certain probes. For more information, refer to ‘Probe List’ in ‘Chapter
5. Probes’.
Panoramic Imaging is the function that acquires images over a wider range by using continuous
ultrasonographic images. Up to 1,000 frames can be used.
Acquiring a Panoramic Image
1. Tap Panoramic on the touchscreen. The touchscreen will be switched to the Panoramic Ready
screen.
2. Tap Start/Stop on the touchscreen. The system will begin to acquire a panoramic image.
3. Press Start/Stop to nish acquiring the panoramic image. The touchscreen will switch to the
Panoramic Review screen.
Tips!
Things to remember when acquiring a Panoramic image
X
When scanning a curved surface, ensure that the scan surface and the contact surface of the
probe are always at right angles.
X
Moving in the opposite direction while acquiring an image erases the previously saved frames
and saves new frames.
X
The image quality may deteriorate if the contact surface of the probe loses contact with the
scan surface.
X
If the scan speed is fast or the angle of the contact surface of the probe changes, artifacts may
occur.
Reviewing a Panoramic Image
NOTE:
X
You can perform basic measurements by using the Caliper button. But other functions on the
control panel are not available.
X
L/R Flip, U/D Flip, and Zoom are available only when the Layout is set to Full Screen.
X
L/R Flip: Flip the panoramic image horizontally.
X
U/D Flip: Flip the panoramic image vertically.
