Samsung HT-D7200 - Specifications and Contact Info

English 71
06 Other Information
Specifi cations
General
Weight 1.0 kg
Dimensions 380 (W) x 23 (H) x 158 (D) mm
Operating Temperature Range +5°C to +35°C
Operating Humidity Range 10 % to 75 %
FM Tuner
Signal/noise ratio
55 dB
Usable sensitivity 12 dB
Total harmonic distortion
0.5 %
Disc
BD (Blu-ray Disc) Reading Speed : 9.834 m/sec
DVD (Digital Versatile Disc)
Reading Speed : 6.98 ~ 7.68 m/sec.
Approx. Play Time (Single Sided, Single Layer Disc) : 135 min.
CD : 12cm (COMPACT DISC)
Reading Speed : 4.8 ~ 5.6 m/sec.
Maximum Play Time : 74 min.
Video Output
Composite Video
1 channel : 1.0 Vp-p (75 Ω load)
Blu-ray Disc : 576i/480i DVD : 576i/480i
Video/Audio
HDMI
1080p, 1080i, 720p, 576p/480p
PCM multichannel audio, Bitstream audio, PCM audio
Amplifier
Front speaker output 133W x 2(3 Ω )
Subwoofer speaker output 134W(3Ω)
Frequency response
Analogue input 20Hz~20kHz (±3dB)
Digital input 20Hz~40kHz (±-4dB)
S/N Ratio 70dB
Channel separation 60dB
Input sensitivity (AUX)500mV
Speaker
Speaker system
2.1ch speaker system
Front Subwoofer
Impedance 3 Ω 3 Ω
Frequency range 140Hz~20kHz 40Hz~160Hz
Output sound pressure level 86dB/W/M 88dB/W/M
Rated input 133W 134W
Maximum input 266W 268W
Dimensions (W x H x D)
Front : 122 x 530 x 120 mm
Subwoofer : 393 x 292 x 390 mm
Weights
Front : 1.18 kg
Subwoofer : 7.5 kg
*: Nominal specifi cation
- Samsung Electronics Co., Ltd reserves the right to change the specifi cations without notice.
- Weight and dimensions are approximate.
- Design and specifi cations are subject to change without prior notice.
- For the power supply and Power Consumption, refer to the label attached to the product.
