Samsung Electronics
3-3
Installation
2. Setting of wired remote controller
• Put off the set power where the wired remote controller is installed.
• Put on the option switch SW 2 of wired remote controller.
• Put on the set power where the wired remote controller is installed.
Caution :
• During the connection, connect the “R1” of indoor unit terminal board installed in each chamber with “R1”.
• During the connection, connect the “R3” of indoor unit terminal board installed in each chamber with “R3”.
• Do not connect the terminal R2 of indoor unit terminal board from “B” to “F” chamber except “A” chamber.
• The option item, centralized controller shall be removed since the simultaneous use with wired remote controller is disable
during the group control.
• Adjust the address of indoor unit rotary switch installed in each chamber so that it might not be duplicated.
Caution :
• The option can be applied when the power is put again after resetting the option of wired remote controller. Be sure to keep the
set power on/off after option setting.
2-00216A(1)-PR 5/19/01 10:05 AM Page 3-3
