6-4
Samsung Electronics
Exploded views and parts list
NO
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
CODE NO
DB90-1056JA
DB63-30028C
DB67-50067A
DB31-00060A
DB31-00060C
DB90-30028E
DB61-40088A
DB93-00317E
DB67-30025A
DB90-20085K
DB62-40011F
DB62-40092A
DB90-10582A
DB90-10085B
DB72-00236A
DB95-10057J
DB73-10023A
DB67-90017B
DB96-00304A
DB96-00925A
DB96-30353A
DB96-00559A
DB32-00021C
DB90-00194A
DB63-30110C
DB95-30013F
PD-DH3200-S4
Description
CABI OUT FRONT
GUARD-INLET
FAN-PROPELLER
MOTOR FAN
MOTOR FAN
ASSY-MOUNT MOTOR OUT
HOLDER-FRAME
ASSY CONTROL OUT
PARTITION
ASSY-BASE OUT
ASSY-VALVE 3/8”
ASSY-VALVE 3/4”
ASSY-CABI OUT SD
ASSY-CABI OUT UP SD
INSULATION-SOUND
ASSY-COMP-SCROLL
GROMMET-MOUNT
HANDLE
ASS’Y 4WAY V/V
ASS’Y CHECK V/V
ASS’Y COND UP PART
ASS’Y COND LOW PART
THERMISTOR COND
ASSY-PLATE-TOP
SCREEN-GUARD
ASS’Y HEATER COMP
ASS’Y PCB PART
Specification
KFH45PY1, SILIT
–, –, SC-91438T, –
ABS+GF20, D495, 4BLADE
OSME-1146SRC(S541)
OSME-1146SRC(S540)
APE-1600CR, –
SGCC1, T1.6, –, –
ADH4400G
SBHG1, T1, –, 389.17x1239.46
AP-3508, M8 WELD BOLT
AP-3508, 3/8”
AP-3508, 3/4”
AP-1100, ASSY SPOT
AP-1004/1604CR, –
T12, W710, L410, FELT
ZR61KC-TFD
EPDM, BLK
ABS, –, SC-90073R
CH44ZAX
DH44ZAX
ASS’Y
ASS’Y
ASS’Y, DH44ZAX
CH44ZAX, –
P.E.H 100%, T2.5, –, –
80W
DH44ZAX
Q’TY
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
4
3
1
1
1
1
1
1
1
1
1
Remark
■ Outdoor Unit Parts list
