Samsung MAX-445 - CD DECK

Samsung Electronics7-6
CMSP30NM6
AH61-10022C
AH63-30048A
AH66-20016A
AH66-20017A
AH66-20018A
AH71-50036A
15253-503-011
AH66-90018A
AJ30-200013B
AH61-60055A
AH31-10009A
AH31-10002B
AH60-10014A
12001-0052-02
13313-0057-00
11474-0017-00
11474-0018-00
11474-0019-00
11404-0041-00
15253-503-011
12223-0003-00
*SOH-AP
12724-0062-00
16829-0004-00
14769-057-250
17008-120-032
DECK -CD
CHASSIS-DECK(M)
COVER-GEAR
GEAR(A)
GEAR(B)
GEAR(C)
SHAFT-PU
CENTER-RING
TURN-TABLE(M)
PICK-UP CDP
SPRING-T/TABLE
MOTOR-SPINDLE
MOTOR-FEED
SCREW-PH(+M2*3)
BASIC
CMSA30 POM M90-44
CMS-V30 BLK ABS
CMS-V30 M0.3 Z13 SP POM
CMS-V30 M0.3 Z13 SP POM
CMS-V30 M0.3 Z16/Z90 SP POM
CMS-V30 D3 L79 SUS420J2
ABS+GS 20% CMS-V10N
ABS+GS 20% CMS-V10N
P/U SOH-A1 ROW V-P/J
CS STS-W PI0.4 D5.7 L9.3 CMS-V10N
RF-310T-11400 43L 25V 85mA
RF-310TA 30MM NDM4RA3ETL 11.0MM
+M2X3 FE FZY W700
1
2
3
4
5
6
7
8
9
10
11
12
13
No. New Code No. Description Specification Old Code No.
7-4 CD DECK
7-4-1 Parts List
7-2 Exploded View
Exploded Views and Parts List
