Samsung MAX-445 - Tray Disassembly; Main Disassembly; CD Main PCB Disassembly

Samsung Electronics 3-5
Disassembly and Reassembly
3-5 CD Mecha Continued
3-5-1 Tray Disassembly
3-5-2 Main Disassembly
3-5-3 CD Main PCB Disassembly
1. Remove the Tray-Roulette (3) from the Tray-Disc AssÕy (4) by releasing the hook.
2. Remove the PCB-Sensor AssÕy (5) from the tray by releasing the hook.
3. Remove the Worm-Motor AssÕy ()) from the Tray-Disc AssÕy (4).
4. Remove the Cushion-Motor (1) from the Tray.
5. Remove the Gear-Roulette (2) from the Tray-Disc AssÕy (4) by releasing the hook.
* When removing, take extreme care not to damage the hook.
1. Open the Tray Disc AssÕy by turning the Gear-Load (%) in the direction of open, then remove the
Wire-Tray (Q) .
2. Remove two Tray-Stopper and tray.
1. Remove the Table-Chuck AssÕy (6) from the Base-Main by turning it.
2. Push the Slider-Cam (!) towards right, then lift it up to remove.
3. Remove the Gear-Tray (^) from the Base-Main by releasing the fixed hook.
4. Remove the Gear-Converter (&) from the Base-Main by releasing the fixed hook.
5. Remove the Gear-Cam (%) from the Base-Main by releasing the fixed hook.
6. Remove the Belt (@) from the Pulley-Motor AssÕy (7) & the Gear-Pulley (#).
7. Remove the Gear-Pulley (#) from the Base-Main by releasing the fixed hook.
8. Remove the Gear-Load ($).
9. Remove the Gear-Synchro (*).
10. Desolder two soldering points of the CD SUB PCB, then remove it from the Base-Main by releasing
the hook.
11. Remove the Pully-Motor AssÕy (7) by releasing the hook.
12. Remove the PCB-SW AssÕy (8) by releasing the hook.
1. Remove the Lever-Lifter (9) from the Base-Main by releasing two hooks.
2. Remove four Rubber-CD (0) from the Lever-Lifter and then remove the Deck-CD ( “ ).
3. Remove the Hook .
4. Remove the CD Main PCB with the soldering iron.
