Samsung MAX-445 - Electrical Parts List

AH90-10722F ASS’Y PCB MAIN; MAX445/455
FD1,2,3,4,BD1,2,5,6,8 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,5
JD1,4,5,6,7,HD1,2
CD1,2,3,4,5,AD101,103
RD6
RD9,11,12,AD104 0402-000127 DIODE-RECTIFIER;1N4002,100V,1A,DO-4 A4104-0053
RD7,8,13 0402-000151 DIODE-RECTIFIER;1N5392,100V,1.5A,DO 12169-201-140
RD1 0402-000450 DIODE-BRIDGE;PBL403,200V,4.0A,DIP-4 12169-219-330
CZD2,3 0403-000354 DIODE-ZENER;UZ5.1B,5.1V,4.8-5.4V,50 12169-403-310
BZD1 0403-000374 DIODE-ZENER;UZ9.1BSC,9.1V,8.89-9.29 12169-404-840
RD5 0403-000377 DIODE-ZENER;UZP10B,10V,9.4-10.6V,1W 12169-403-240
RD3 0403-000389 DIODE-ZENER;UZP30B,30V,28-33V,1W,DO A4106-0121
HZD1,RD16 0403-000394 DIODE-ZENER;UZP5.6B,5.6V,5.2-6.0V,1 12169-404-110
RD4 0403-000396 DIODE-ZENER;UZP6.8B,6.8V,6.4-7.2V,1 12169-404-100
IZD1 0403-000398 DIODE-ZENER;UZP8.2B,8.2V,7.7-8.7V,1 12169-403-600
LQ1L,1R,2L,2R 0501-000010 TR-SMALL SIGNAL;KSC1008-Y,NPN,80V,6 12149-301-050
FQ3,CQ6 0501-000294 TR-SMALL SIGNAL;KSA708-Y,PNP,800MW, 12149-101-560
CQ4 0501-000303 TR-SMALL SIGNAL;KSA733-Y,PNP,250MW, 12149-101-520
RQ1 0501-000331 TR-SMALL SIGNAL;KSC1009-Y,NPN,800MW 12139-301-310
FQ1,2 0501-000392 TR-SMALL SIGNAL;KSC838-O,NPN,250MW, 12149-301-860
FQ001,LQ6,AQ103L,103R 0501-000394 TR-SMALL SIGNAL;KSC900-L,NPN,250MW, 12149-301-840
HQ3,CQ5,8,BQ5,6,JQ1L,1R 0501-000398 TR-SMALL SIGNAL;KSC945-Y,NPN,250MW, 12149-301-900
CQ7 0501-000610 TR-SMALL SIGNAL;KSA928A-Y,PNP,1W,TO
RQ2 0502-000148 TR-POWER;2SB1185,PNP,2W,TO-220FP,BK B4052-0035
JQ2L,2R,3L,3R,8,CQ9,AQ102 0504-000121 TR-DIGITAL;KSR1007,NPN,300MW,22K-47 12159-301-800
JQ9L,9R,PQ2L,2R,CQ10 0504-000122 TR-DIGITAL;KSR1009Y,NPN,300MW,4.7K, 12159-301-790
CQ1,JQ4,5,6,AQ101,PQ1 0504-001003 TR-DIGITAL;KSR2003,PNP,300MW,22K-22
RQ3
ZIC1,BIC2 1201-000192 IC-OP AMP;4558,SIP,9P,-,DUAL,20V/MV 12119-401-630
JIC1 1201-000358 IC-PREAMP;22291,DIP,24P,-,DUAL,-,PL A4012-0070
RIC1 1203-000166 IC-POSI.ADJUST REG.;3950,SIP,12P,-, B4008-1198
BIC1 1204-000235 IC-VOLUME CONTROL;TDA7318,SOP,28P,- B4008-1199
FR4 2001-000005 R-CARBON;390OHM,5%,1/8W,AA,TP,1.8X3 11018-877-391
JR9L,9R 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-153
LR3 2001-000032 R-CARBON;180OHM,5%,1/4W,AA,TP,2.4X6 11018-277-181
AR121,122 2001-000062 R-CARBON;470OHM,5%,1/4W,AA,TP,2.4X6 11018-277-471
RR7 2001-000066 R-CARBON(S);10KOHM,5%,1/2W,AA,TP,2. 11018-377-103
IR10 2001-000117 R-CARBON(S);68OHM,5%,1/2W,AA,TP,2.4 11018-377-680
IR14L,14R 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X 11018-877-152
BR3L,3R,HR10,CR7 2001-000273 R-CARBON;100KOHM,5%,1/8W,AA,TP,1.8X 11018-877-104
FR17 2001-000281 R-CARBON;100OHM,5%,1/8W,AA,TP,1.8X3 11018-877-101
BR4,5L,5R,HR42,43,JR15,27 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-103
CR6,15,20,HR23,JR37,AR130
SR1L,1R,35,37,JR17,29
LR4,6,IR13 2001-000331 R-CARBON;12KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-123
RR16 2001-000411 R-CARBON;18KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-183
FR5,HR4,CR10,ZR10,IR11 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3. 11018-877-102
BR6L,6R,10,11,HR2
8. Electrical Parts List
Samsung Electronics 8-1
Loc No. New Code No. Description Specification Old Code No.
