Samsung MAX-670 - Cassette Deck Section

3KHZ 1%
5700~6300KHz
Samsung Electronics4-2
Alignment and Adjustments
4-2 Cassette Deck Section
1) Measuring Tape i) MTT-111(or equivalent)
(Tapes recorded with 3kHz )
ii) MTT-5512(or equivalent)
2) Connect the Cassette Deck to the
frequency counter as in Figure 4-5
Note
4-2-1 To Adjust Tape Speed
Figure 4-5
Cassette Deck
Frequency Counter
Line Out
TP1
Output
LSR1R
LSR1L
JSR3R
JSR2R
JSR1R
CSR1
TP3
CSR2
LL2
TP1
TP2
NOR
SPEED
Control
counter
HI SPEED
Control
OUT
(connected
tothe
frequency
counter)
Same as
above
1) A-Deck: MTT-111
2) Press PLAY SW
button
3) B-Deck: Same as
below
1) A-Deck: MTT-111
2) B-Deck: MTT-5512
3) Press Hi Speed
dubbing switch
Turn CSR1,2 to
left and right.
Fixed
Check
1
2
Step
To Adjust
Item
Standard
Remark
Pre-Setup
Condition
Pre-Setup
