AH90-10485E ASSY-MAIN PCB;MAX670R/CHN,DOMESTIC
TD5,6,7,8,ED1,2,3,4,PD9 0401-000101 DIODE-SWITCHING;1N4148,100V,200MA,5
TD1,2,3,4,ED5,6,7,8
PD1,2,3 0402-000125 DIODE-RECTIFIER;1N4001,50V,1A,DO-41 A4104-0001
PBD1 0402-000450 DIODE-BRIDGE;PBL403,200V,4.0A,DIP-4 12169-219-330
PBD2 0402-001010 DIODE-BRIDGE;GBU6D,200V,6A,SIP-4
PZD12 0403-000342 DIODE-ZENER;UZ3.6BSA,3.6V,3.47-3.68 12169-404-770
PZD6,KZD1 0403-000355 DIODE-ZENER;UZ5.1BSB,5.1V,4.97-5.18 12169-404-780
PZD4 0403-000358 DIODE-ZENER;UZ5.6BSB,5.6V,5.46-5.7V 12169-404-790
PZD13 0403-000369 DIODE-ZENER;UZ8.2BM,8.2V,7.9-8.5V,5 12169-403-290
EZD1,PZD7 0403-000374 DIODE-ZENER;UZ9.1BSC,9.1V,8.89-9.29 12169-404-840
PZD2 0403-000391 DIODE-ZENER;UZP36B,36V,34-39V,1W,DO A4106-0115
DZD1 0403-000393 DIODE-ZENER;UZP5.1B,5.1V,4.8-5.4V,1 12169-403-330
VZD1,PZD1 0403-000394 DIODE-ZENER;UZP5.6B,5.6V,5.2-6.0V,1 12169-404-110
TZD1 0403-000398 DIODE-ZENER;UZP8.2B,8.2V,7.7-8.7V,1 12169-403-600
TQ6,VQ1,2 0501-000294 TR-SMALL SIGNAL;KSA708,PNP,800MW,TO 12149-101-560
PQ13 0501-000369 TR-SMALL SIGNAL;-,NPN,1W,TO-92L,-,1 12149-301-910
TQ7,9 0501-000392 TR-SMALL SIGNAL;-,NPN,250MW,TO-92,- 12149-301-860
TQ8 0501-000398 TR-SMALL SIGNAL;KSC945,NPN,250MW,TO 12149-301-900
PQ12,3,VQ3,4,TQ5 0501-000407 TR-SMALL SIGNAL;-,NPN,800MW,TO-92,- 12149-401-150
PQ1 0502-000304 TR-POWER;-,NPN,1W,TO-126,TP,60-400 12149-401-900
PQ2 0502-000424 TR-POWER;2SB1566-F,PNP,2W,TO-220FN, B4052-0086
PQ11 0504-000203 TR-DIGITAL;-,NPN,300MW,47K-47K,TO-9
DIC2,HIC1,FIC2,EIC2 1201-000163 IC-OP AMP;4560,SOP,8P,150MIL,DUAL,1 12119-401-300
PIC2 1203-000110 IC-NEGA.FIXED REG.;7912,TO-220,3P,- 12109-401-700
PIC3 1203-000242 IC-POSI.FIXED REG.;7812,TO-220,3P,- 12109-401-690
PIC1 1203-000294 IC-POSI.FIXED REG.;7808,TO-220,3P,- 12109-401-730
FIC1 1204-000235 IC-VOLUME CONTROL;TDA7318,SOP,28P,- B4008-1199
PR1-1,PR2-2,PR3-3,PR4-4 13954-100-310 CERAMIC-PIPE;PI1.4 15MM WHT
ER3,10 2001-000008 R-CARBON;15KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-153
KR18 2001-000028 R-CARBON(S);100OHM,5%,1/2W,AA,TP,2. 11018-377-101
PR12 2001-000038 R-CARBON;390OHM,5%,1/4W,AA,TP,2.4X6 11018-277-391
PR8 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X 11018-877-152
HR12,13,TR6 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-103
JW179 2001-000302 R-CARBON;10OHM,5%,1/8W,AA,TP,1.8X3. 11018-877-100
VR2 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3 11018-877-151
TR20 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3. 11018-877-102
ER5,7,DR15,16,TR56,64 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X 11018-877-222
VR7,8,ER34,TR66
ER6,8 2001-000508 R-CARBON;220KOHM,5%,1/8W,AA,TP,1.8X 11018-877-224
TR5,52,PR7,VR5,3 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-223
ER18,19,PR6,TR4,7
TR69 2001-000525 R-CARBON;22OHM,5%,1/4W,AA,TP,2.4X6. 11018-277-220
ER1,2,22,VR9,TR68 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X 11018-877-472
VR10,PR30,29 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X 11018-877-472
VR4,6 2001-000780 R-CARBON;470OHM,5%,1/8W,AA,TP,1.8X3 11018-877-471
TR53 2001-000786 R-CARBON;47KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-473
PR16,TR25 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X 11018-877-562
Loc No. New Part No. Description Specification Old Part No.
8. Electrical Parts List
Samsung Electronics 8-1
