BIAS,LEVEL,SIGNAL 3711-000907 CONNECTOR-HEADER;BOX,3P,1R,2MM,STRA 13349-119-030
R/P HEAD 3711-001011 CONNECTOR-HEADER;BOX,5P,1R,2.5MM,ST 13349-103-053
CFN3 3809-000183 CABLE-FLAT;30V,80C,300MM,34P,1.25MM A6032-0054
CCN1 3809-000203 CABLE-FLAT;30V,80C,300MM,16P,1.25MM A6032-0085
CCN2 3809-001009 CABLE-FLAT;30V,80C,250MM,18P,1.25MM
CCN1 3809-001010 CABLE-FLAT;30V,80C,300MM,12P,1.25MM
UIC1 AH09-10060C IC-MCU;LC866224-XXXX,100P,QFP,-
JIC2,UIC2 AH14-10007D IC;NJU3716M,SOP,STICK EXPANDER 16BI
JLPF2L,2R,3L,3R AH26-10002X COIL-TRAP;KS940830-05,BIAS-TRAP,30D 12429-206-102
LL2 AH26-10003C COIL-TRAP;PCHNS-5371EQJ,BIAS-TRAP,- 12619-577-771
CDN1 AH39-20022G LEAD-CONNECTOR ASS’Y;51004,5295,8P, 16439-0204-00
H/SINK AH62-30112A HEAT SINK-TR;-,ALS,-,T4.0,BLK ANODI
CCW1 B6010-1502 CONNECTOR-FPC;52045-1245 GRY J/MOLE
AH90-10690A ASSY-PCB FRONT;MAX670Z,CHN
UQ6 0501-000407 TR-SMALL SIGNAL;-,NPN,800MW,TO-92,- 12149-401-150
ULD12,13 0601-000245 LED;ROUND,RED,3.1MM,650NM 12309-001-450
ULD16,17,18,19,20,21 0601-001051 LED;ROUND,GRN/RED,3.2MM,563/650NM
ULD22,23,24,25,26,27
ULD28,29,11,30
ULD1,2,3,5,7,9,14,15
ULD4,6,8,10
UR27,33,41 2001-000221 R-CARBON;1.2KOHM,5%,1/8W,AA,TP,1.8X 11018-877-122
UR22
UR28,34,42,43,35 2001-000241 R-CARBON;1.5KOHM,5%,1/8W,AA,TP,1.8X 11018-877-152
UR49 2001-000290 R-CARBON;10KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-103
UR11,14,16,17,105,108 2001-000362 R-CARBON;150OHM,5%,1/8W,AA,TP,1.8X3 11018-877-151
UR106,107,60
UR12,13,15,18,109,110 2001-000405 R-CARBON;180OHM,5%,1/8W,AA,TP,1.8X3
UR111,112,61
UR32,40,26 2001-000429 R-CARBON;1KOHM,5%,1/8W,AA,TP,1.8X3. 11018-877-102
UR36,44 2001-000449 R-CARBON;2.2KOHM,5%,1/8W,AA,TP,1.8X 11018-877-222
UR45,59 2001-000472 R-CARBON;2.7KOHM,5%,1/8W,AA,TP,1.8X 11018-877-272
UR19 2001-000515 R-CARBON;220OHM,5%,1/8W,AA,TP,1.8X3 11018-877-221
UR50,51 2001-000522 R-CARBON;22KOHM,5%,1/8W,AA,TP,1.8X3 11018-877-223
UR20,21 2001-000554 R-CARBON;270OHM,5%,1/8W,AA,TP,1.8X3 11018-877-271
UR46 2001-000613 R-CARBON;3.9KOHM,5%,1/8W,AA,TP,1.8X 11018-877-392
UR65,66,67,68,69,70,71 2001-000734 R-CARBON;4.7KOHM,5%,1/8W,AA,TP,1.8X 11018-877-472
UR72,73,74,75,76,77
UR78,79,80
UR52,53,54,55,56,57,58 2001-000793 R-CARBON;47OHM,5%,1/8W,AA,TP,1.8X3. 11018-877-470
UR47,62 2001-000812 R-CARBON;5.6KOHM,5%,1/8W,AA,TP,1.8X 11018-877-562
UR23,29,37 2001-000857 R-CARBON;560OHM,5%,1/8W,AA,TP,1.8X3 11018-877-561
UR6,10 2001-000869 R-CARBON;56OHM,5%,1/8W,AA,TP,1.8X3. 11018-877-560
UR48 2001-000890 R-CARBON;6.8KOHM,5%,1/8W,AA,TP,1.8X 11018-877-682
UR24,30,38 2001-000924 R-CARBON;680OHM,5%,1/8W,AA,TP,1.8X3 11018-877-681
UR25,31,39 2001-000995 R-CARBON;820OHM,5%,1/8W,AA,TP,1.8X3 11018-877-821
USW1,2,3,4,5,6,7 3404-000165 SWITCH-TACT;12V,50MA,160GF+-50GF,6X 13559-901-100
USW8,9,10,11,12,13,14
USW15,16,17,18,20,21
Loc No. New Part No. Description Specification Old Part No.
Electrical Parts List
Samsung Electronics 8-11
