System Overview
Samsung Electronics
Service Manual
3-1
3
3
3. System Overview
3.1 System Outline
Paper Path Layout
BIN PATH
❶ SMPS ❷ Fuser
❸ Toner Cartridge ❹ LSU
❺ Exit Roller ❻ OPC
❼ Pick-Up Roller ❽ KNOCK-UP PLATE
❾ KNOCK-UP PLATE DOWN ❿ ASS’Y HOLDER PAD
󱆌 Feed Sensor 󱆍 MAIN PBA
󱆎 SMPS 󱆏 HVPS
󱆏
