49
Bottom View
1
Battery Latches
The latch used to remove or install the battery.
2
Sub-Woofer Speaker
(Optional)
A device used to produce mid and low frequency sound louder.
3
Memory Compartment
Cover
The main memory is installed inside the cover.
4
Fan Vents
The internal heat of the computer is emitted through these holes.
If the vents are blocked the computer may overheat.
Avoid blocking the vents as this may be dangerous.
5
Speaker
A device used to generate sound.
1
3
5
2
4
