Samsung NP-R538E User Manual (FreeDos) Service Manual

6-1
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
R530/R730
6. Material List
6-1. 15" Material List
Level Code Assembled EA Description Spec. Service
..1 0203-001869 KAPTON_MICOM 0.05 TAPE-KAPTONE K-CJ01,T0.06,W10,L33000mm,YELLOW,ROLL TYPE
..1 0203-001869 KAPTON_RTC BAT 0.05 TAPE-KAPTONE K-CJ01,T0.06,W10,L33000mm,YELLOW,ROLL TYPE
..1 4301-000108 RTC BAT 1 BATTERY-LI 3V,220mAH,CR2032,20x3.2mm,NO,3.3g,Button Cell
..1 4301-001070 RTC BAT 1 BATTERY-LI 3V,210mAH,CR2032,20x3.2mm,NO,2.9g,Button Cell
..1 6001-001570 HDD SCREW 2 SCREW-MACHINE CH,+,M2,L4,ZPC(BLK),SWRCH18A,FP,NYLOCK,T1.0
..1 6001-001570 ODD SCREW 2 SCREW-MACHINE CH,+,M2,L4,ZPC(BLK),SWRCH18A,FP,NYLOCK,T1.0
..1 6001-001570 WLAN+MAIN PCB 1 SCREW-MACHINE CH,+,M2,L4,ZPC(BLK),SWRCH18A,FP,NYLOCK,T1.0
..1 BA41-01201A ODD FFC 1 FFC-ODD BREMEN,1.0,FILM,12PIN,T0.3,L61XW6.5MM,ODD FFC,-,-
..1 BA59-02572A WLAN-802.11BGN 1 MODULE-WLAN AR5B95,WLL6160-D99(ROHS),-,1x1,Half MiniCard Standard,-,-,-
,W308*L26.88*H4.75mm,-,Atheros 802.11bgn compliant,-
..1 BA68-40005L PBA SN LABEL 1 LABEL-BARCODE NOTE PC,-,ART PAPER,-,W40.0,L6.0MM,-,-,-,-,-,-,-
..1 BA75-01937A M502 1 UNIT-BRACKET_CPU PALAU,SEC,SPCC,W50*L40*T1.5mm,-,-,-,PBA
..1 BA81-04279A RUBBER-SUPPOR 1 RUBBER-SUPPORT TORINO2-VE,DOMESTIC,SILICON
RUBBER,W5*L5*H1.4mm,BLACK,RUBBER-SUPPORT,-
..1 BA81-04683A BRAKET-VGA 1 BRACKET-VGA LYON,SUS 0.15T,W28.1*L11.0mm,NTR,-,-,-
..1 BA81-07333A RUBBER MIC 1 RUBBER-MIC BONN-L,TPU,D13.1*H3.7mm,BLACK,-,-,-
..1 BA81-08240A INSULATOR_HDMI 1 INSULATOR-HDMI BONN,PC,W12*L6*T0.2mm,BLACK,-,-
..1 BA92-06119B SMT 1 ASSY MOTHER BD-SMT BREMEN-UL,PGA,DDR2,-,-,-,SMT,PV/CONFIG1
....2 BA92-06119C SMT_U 1 ASSY MOTHER BD-
SMT_U
BREMEN-UL,PGA,DDR2,-,NT,-,SMT_U,PV/CONFIG1
......3
0401-000132 D500 1 DIODE-SWITCHING BAV99,70V,50mA,SOT-23,TP
......3 0401-000132 D501 1 DIODE-SWITCHING BAV99,70V,50mA,SOT-23,TP
......3 0401-000132 D503 1 DIODE-SWITCHING BAV99,70V,50mA,SOT-23,TP
......3 0401-000191 D505 1 DIODE-SWITCHING MMBD4148,100V,200mA,SOT-23,TP
......3 0404-001020 D512 1 DIODE-SCHOTTKY BAT54C,30V,200mA,SOT-23,TP
......3 0404-001084 D510 1 DIODE-SCHOTTKY BAT54A,30V,200mA,SOT-23,TP
......3 0404-001084 D511 1 DIODE-SCHOTTKY BAT54A,30V,200mA,SOT-23,TP
......3 0505-001088 Q500 1 FET-SILICON AO4807L,P,-30V,6A,0.028/0.035ohm,2W,SOIC-8
......3 0505-001844 Q501 1 FET-SILICON SI4435DDY-T1-GE3,P,-30V,-11.4A,0.024ohm,5W,SO-8
......3 0505-001883 Q28 1 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323
......3 0505-001883 Q504 1 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323
......3 0505-001883 Q505 1 FET-SILICON RHU002N06,N,60V,200MA,3.3OHM,0.15W,SOT-323
......3 0505-002166 Q503 1 FET-SILICON SI2307BDS,P,30V,3.2A,0.063ohm,0.8W,SOT-23
......3 0505-002386 Q502 1 FET-SILICON AO3415AL,P,-20V,-4A,0.045ohm,1.5W,SOT-23
......3 0601-002037 LED518 1 LED SMD(TOP VIEW),BLUE,1.6x0.8mm,465/470nm,1.6x0.8x0.4mm
......3 0601-002037 LED519 1 LED SMD(TOP VIEW),BLUE,1.6x0.8mm,465/470nm,1.6x0.8x0.4mm
......3 0601-002037 LED520 1 LED SMD(TOP VIEW),BLUE,1.6x0.8mm,465/470nm,1.6x0.8x0.4mm
......3 0601-002037 LED522 1 LED SMD(TOP VIEW),BLUE,1.6x0.8mm,465/470nm,1.6x0.8x0.4mm
......3 0601-002391 LED521 1 LED SMD,RED/GRN,1.6x1.5x0.55mm,574~639nm,1.6x1.5x0.55mm
......3 0601-002846 LED500 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED501 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED502 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED503 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED504 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED505 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED506 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED507 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED508 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED509 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED510 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED511 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED512 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED513 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED514 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED515 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED516 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 0601-002846 LED517 1 LED SMD(TOP VIEW),WHT,1.6x0.8x0.4mm
......3 1009-001010 U500 1 IC-HALL EFFECT S/W A3212ELH/HED55XXU12,SC-59A,3P,82MIL,TP,PLASTIC,3.5V,2mA,-
40to+85C,-,-
......3 1107-001709 U506 1 IC-FLASH MEMORY MX25L1605DM2I-12G,16Mbit,2Mx8,SOP,8P,5.28x5.23mm,86MHz,2.7/
3.6V,-40to+85C,20uA,TP
