Page #43 background imageLoading...
Page #43 background image
6-19
6. Material List
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
R530/R730
Level Code Assembled EA Description Spec. Service
......3 2801-004874 Y500 1 CRYSTAL-SMD 14.31818MHz,50ppm,-,16,40ohm,TP
......3 2801-004875 Y1 1 CRYSTAL-SMD 25MHz,50ppm,-,10,40ohm,TP
......3 3301-001272 B1 1 BEAD-SMD 120ohm,2x1.25x1mm,TR,-,-
......3 3301-001272 B2 1 BEAD-SMD 120ohm,2x1.25x1mm,TR,-,-
......3 3301-001649 B15 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B16 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B17 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B18 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B19 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B20 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B21 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B22 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B23 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B24 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B25 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B26 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B3 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B4 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B5 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B6 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B7 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B8 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3301-001649 B9 1 BEAD-SMD 180ohm,1608,TP,226ohm/389MHz
......3 3404-001311 SW1 1 SWITCH-TACT 12VDC,50mA,100gf,6.0x6.0x5.0mm,SPST
......3 3704-001153 CPU1 1 SOCKET-IC 479P,PGA,AU,1.27mm
......3 3709-001492 J4 1 CONNECTOR-CARD
SLOT
9P,2.5mm,SMD-A,AU,2 IN 1
......3 3709-001498 J3 1 CONNECTOR-CARD
EDGE
52P,0.8mm,SMD-A,AU,MINI PCI Express
......3 3709-001572 DDR2M1 1 CONNECTOR-CARD
EDGE
200P,0.6mm,SMD-A,AU,SODIMM
......3 3709-001573 DDR2M2 1 CONNECTOR-CARD
EDGE
200P,0.6mm,SMD-A,AU,SODIMM
......3 3710-002788 JHDD1 1 SOCKET-INTERFACE 7+15P,1R,1.27mm,SMD-A,AU,BLK
......3 3711-000386 J5 1 HEADER-BOARD TO
CABLE
BOX,10P,1R,1.25MM,SMD-S,SN,WHT
......3 3711-000456 J2 1 HEADER-BOARD TO
CABLE
BOX,4P,1R,1.25mm,SMD-S,SN,NTR
......3 BA61-01090A M1 1 SUPPORT-MINICARD RIMINI,ALLOY,T1.5,W4.5,L1.5mm,NTR,-,-
......3 BA81-07945B SMT11 1 LEAD-1005 NP,SMT_SHORT,SOLDER-CREAM,0 OHM,-,-,-
......3 BA81-07945B SMT12 1 LEAD-1005 NP,SMT_SHORT,SOLDER-CREAM,0 OHM,-,-,-
......3 BA81-07945B SMT13 1 LEAD-1005 NP,SMT_SHORT,SOLDER-CREAM,0 OHM,-,-,-
......3 BA81-07945B SMT14 1 LEAD-1005 NP,SMT_SHORT,SOLDER-CREAM,0 OHM,-,-,-
......3 BA81-07945B SMT15 1 LEAD-1005 NP,SMT_SHORT,SOLDER-CREAM,0 OHM,-,-,-
......3 BA81-07945B SMT16 1 LEAD-1005 NP,SMT_SHORT,SOLDER-CREAM,0 OHM,-,-,-
......3 BA81-07945B SMT4 1 LEAD-1005 NP,SMT_SHORT,SOLDER-CREAM,0 OHM,-,-,-
..1 BA99-07566A SUB MATERIAL 1 ASSY SUB/MATERIAL-
NP_PBA
N/P,PBA SUB/MATERIAL,WIRE,FLUX,-
