7-6
R530/R730
7. System Wire Diagram
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
7-6. LCD Assy wire diagram (17.3)
WLAN Ant #2WLAN Ant #1
Camera Module
Camera Cable
LCD cable
Antenna Cable
2ea
