6-21
6. Material List
- 이 문서는 삼성전자의 기술 자산으로 승인자만이 사용할 수 있습니다 -
- This Document can not be used without Samsung's authorization -
R530/R730
Level Code Assembled EA Description Spec. Service
......3 1009-001010 U500 1 IC-HALL EFFECT S/W A3212ELH/HED55XXU12,SC-59A,3P,82MIL,TP,PLASTIC,3.5V,2mA,-
40to+85C,-,-
......3 1107-001709 U506 1 IC-FLASH MEMORY MX25L1605DM2I-12G,16Mbit,2Mx8,SOP,8P,5.28x5.23mm,86MHz,2.7/
3.6V,-40to+85C,20uA,TP
......3 1203-005735 U507 1 IC-PWM CONTROLLER RT8205AGQW,QFN,24P,4x4mm,PLASTIC,2/5.5V,1.923W,-
10to+85C,3A,2.0V,TR
......3 1203-005864 U501 1 IC-PWM CONTROLLER TPS51620RHAR,QFN,40P,6x6x0.9mm,PLASTIC,-0.3/6V,3.125W,-
40to+125C,-,1.685/1.735V,TP
......3 1203-006049 U505 1 IC-PWM CONTROLLER APW7141QAITRG,QFN,14P,3.5x3.5mm,-,-0.75V to 5.5V,80W,-
40to+85C,-,0.75V,TP
......3 1205-002596 SW500 1 IC-SWITCH TPS2062,SOIC,8P,5x6x1.65mm,PLASTIC,5V,585.82mW,-40to+85C,TP,-
......3 1205-002596 SW501 1 IC-SWITCH TPS2062,SOIC,8P,5x6x1.65mm,PLASTIC,5V,585.82mW,-40to+85C,TP,-
......3 1205-003904 U503 1 IC-ETHERNET
CONTROLLER
88E8040-A0-NNB2C000,QFN,48P,7x7mm,PLASTIC,3.465V,332mW,
0to+70C,TR,PCI-E, Fast Ethernet
......3 1209-001887 U502 1 IC-SENSOR EMC2112-BP-TR,QFN,20P,4x4mm,PLASTIC,5.5V,0.9W,0to+85C,TR
......3 2007-000057 R565 1 R-CHIP 40.2Kohm,1%,1/10W,TP,1608
......3 2007-000070 R536 1 R-CHIP 0ohm,5%,1/10W,TP,1608
......3 2007-000077 R530 1 R-CHIP 470ohm,5%,1/10W,TP,1608
......3 2007-000077 R531 1 R-CHIP 470ohm,5%,1/10W,TP,1608
......3 2007-000077 R532 1 R-CHIP 470ohm,5%,1/10W,TP,1608
......3 2007-000077 R533 1 R-CHIP 470ohm,5%,1/10W,TP,1608
......3 2007-000141 R694 1 R-CHIP 2.2Kohm,5%,1/16W,TP,1005
......3 2007-000171 R513 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000171 R514 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000171 R515 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000171 R516 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000171 R517 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000171 R518 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000171 R541 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000171 R542 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000171 R557 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000171 R558 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000171 R768 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000171 R769 1 R-CHIP 0ohm,5%,1/16W,TP,1005
......3 2007-000173 R578 1 R-CHIP 22ohm,5%,1/16W,TP,1005
......3 2007-000173 R579 1 R-CHIP 22ohm,5%,1/16W,TP,1005
......3 2007-000173 R583 1 R-CHIP 22ohm,5%,1/16W,TP,1005
......3 2007-000173 R730 1 R-CHIP 22ohm,5%,1/16W,TP,1005
......3 2007-000173 R731 1 R-CHIP 22ohm,5%,1/16W,TP,1005
......3 2007-000173 R732 1 R-CHIP 22ohm,5%,1/16W,TP,1005
......3 2007-000173 R733 1 R-CHIP 22ohm,5%,1/16W,TP,1005
......3 2007-000173 R734 1 R-CHIP 22ohm,5%,1/16W,TP,1005
......3 2007-000173 R735 1 R-CHIP 22ohm,5%,1/16W,TP,1005
......3 2007-000309 R800 1 R-CHIP 10ohm,5%,1/10W,TP,1608
......3 2007-000503 R644 1 R-CHIP 2.2ohm,5%,1/10W,TP,1608
......3 2007-000695 R527 1 R-CHIP 3.3ohm,5%,1/10W,TP,1608
......3 2007-000695 R548 1 R-CHIP 3.3ohm,5%,1/10W,TP,1608
......3 2007-000695 R660 1 R-CHIP 3.3ohm,5%,1/10W,TP,1608
......3 2007-000695 R663 1 R-CHIP 3.3ohm,5%,1/10W,TP,1608
......3 2007-000695 R665 1 R-CHIP 3.3ohm,5%,1/10W,TP,1608
......3 2007-001313 R678 1 R-CHIP 330ohm,5%,1/16W,TP,1005
......3 2007-001313 R679 1 R-CHIP 330ohm,5%,1/16W,TP,1005
......3 2007-001313 R680 1 R-CHIP 330ohm,5%,1/16W,TP,1005
......3 2007-001313 R681 1 R-CHIP 330ohm,5%,1/16W,TP,1005
......3 2007-001313 R682 1 R-CHIP 330ohm,5%,1/16W,TP,1005
......3 2007-001313 R685 1 R-CHIP 330ohm,5%,1/16W,TP,1005
......3 2007-001313 R798 1 R-CHIP 330ohm,5%,1/16W,TP,1005
......3 2007-001313 R807 1 R-CHIP 330ohm,5%,1/16W,TP,1005
......3 2007-001313 R809 1 R-CHIP 330ohm,5%,1/16W,TP,1005
......3 2007-001313 R811 1 R-CHIP 330ohm,5%,1/16W,TP,1005
......3 2007-001313 R818 1 R-CHIP 330ohm,5%,1/16W,TP,1005
......3 2007-001313 R821 1 R-CHIP 330ohm,5%,1/16W,TP,1005
......3 2007-001313 R823 1 R-CHIP 330ohm,5%,1/16W,TP,1005
......3 2007-001313 R824 1 R-CHIP 330ohm,5%,1/16W,TP,1005
