Samsung OH55A-S User Manual

53
ID Settings
HOME ID SettingsENTER E
ID Settings

The displayed image may differ depending on the model.
Assign an ID to a set.
Device ID
Set a unique ID number for each product. (Range: 0~224)

Press u/d to select a number, and press E.

Enter the number you want using the number buttons on the remote control.
Device ID Auto Set
This feature automatically allots an ID number to a device connected via an RS232C cable.

This function is only available on the first device within an RS-232C daisy chain.
PC Connection Cable
Select which type of cable you are using to connect the display to the PC.
 RS232C cable
Communicate with MDC via the RS232C cable.
 RJ45(LAN) cable
Communicate with MDC via the RJ45 cable.

Samsung OH55A-S Specifications

General

Color gamut	72 %
Pixel pitch	0.63 x 0.63 mm
Response time	6 ms
Display diagonal	55 \
Display brightness	3500 cd/m²
Display technology	VA
Vertical scan range	24 - 75 Hz
Horizontal scan range	30 - 136 kHz
Contrast ratio (typical)	6000:1
Dynamic contrast ratio marketing name	Mega Contrast
Flash memory	8000 MB
Glass protection	Yes
Purpose	Universal
HDCP version	2.2
Operating hours (hours/days)	24/7
International Protection (IP) code	IP56
Orientation	Horizontal/Vertical
Product color	Black
Product design	Digital signage flat panel
Bezel width (side)	24.9 mm
Placement supported	Outdoor
Panel mounting interface	1186 x 560 mm
USB ports quantity	1
DisplayPorts quantity	0
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (sleep)	0.5 W
Power consumption (standby)	- W
Power consumption (typical)	530 W
Package depth	230 mm
Package width	1358 mm
Package height	845 mm
Package weight	52600 g
Operating temperature (T-T)	-30 - 50 °C
Operating relative humidity (H-H)	10 - 80 %
Built-in processor	-
Computer system type	System on Chip (SoC)
Operating system installed	Tizen 5.1

Weight and Dimensions

Display depth	85 mm
Display width	1260.6 mm
Display height	731.4 mm
Display weight	46100 g
