Samsung ProXpress SL-C3010ND - SMPS Board

2.ProductSpecicationanddescription
2.2.5.3.SMPSboard
TheSMPS(SwitchingModePowerSupply)BoardsupplieselectricpowertotheMainBoardandotherboardsthrougha
MainController.TheSMPSboardconvertsACvoltage110V/220VtoDCvoltage+5V ,+24VandtransfersACpowerto
thefuserunit..Ithassafetyprotectionmodesforovercurrentandoverload.
•Specication
-GeneralInput/OutputV oltage
1)Input
▪AC110V(90V~135V)
▪AC220V(180V~270V)
2)Output
▪DC+5V/4.0A
▪DC+24V/6.0A
3)OutputPower
▪DC+5V:20W
▪DC+24V:144W
▪FDB:850W
•Information
110V220V
PartCodeJC44-00222DJC44-00223D
PBANamePSPN2-TYPE3R-V1APSPN2-TYPE3R-V2A
•Connection
1INPUT_AC
2OUTPUT_AC(toFuser)
3OUTPUT_DC(toMainPBA)
4ControlSignal(fromMainPBA)
