3.DisassemblyandReassembly
3.3.17.FRAME-SEPARATIONUNIT
1.Removethecassette.
2.Removetherearcover.(Referto3.2.3.)
3.Removethewastetonercontainer.
4.Remove2screws.Andthen,releasetheCover-Rear
Bottom.
5.Remove6screws.Andthen,removethePlate-Guide
Paper.
6.PulltherightoftheFRAME-SEPARATIONtothe
frontandreleaseit.
7.Unplugtheharness.
