2.ProductSpecicationanddescription
2.2.5.4.HVPSboard
TheHighV oltagePowerSupply(HVPS)boardgenerateshigh-voltagechannelswhichincludesMHV ,DEV ,Blade,SUP ,
THV1,THV2.
•Connection
1MHV/DEV/BLD/SUPY
2MHV/DEV/BLD/SUPM
3MHV/DEV/BLD/SUPC
4MHV/DEV/BLD/SUPK
5THV1YMCK
6THV2
7Main-HVPSI/F#2
8Main-HVPSI/F#1
9Paperexit,Outbinfull
10FuserRelease
11HVPS1–HVPS2
12Fan
13Ambient,Humidity
14CrumC,K
15CrumY ,M
16PaperRegi
17WTBinterface
18HVPS2–HVPS1
19FrontcoveropenSwitch
20RearcoveropenSwitch
•Information
-PartCode:JC44-00242A/JC44-00243A
-PBAName:HVPS
