Samsung RF4287HARS/XAA - 3-9) Foldable Glass Shelf; 3-10) Vegetable & Fruit Drawers Shelf

36
DISASSEMBLY AND REASSEMBLY
3-9) Foldable Glass Shelf
Foldable Glass
Shelf
Part Name How To Do Descriptive Picture
1. Remove the Cap.
2. Remove 2 screws of the
Folderble Glass Shelf.
3-10) Vegetable & Fruit Drawers Shelf
Vegetable &
Fruit Shelf
Part Name How To Do Descriptive Picture
1. Remove the vegetable & fruit
drawer by pulling the roller part
and lifting it up.
2. While pressing the button on the
left of the shelf in the picture, lift
up the Vegetable & Fruit Drawer
Shelf.
(Refer to the picture)
3. Remove the vegetable & fruit
drawer shelf by pulling it out.
(Refer to the picture)
