Samsung RF4287HARS/XAA - 3-25) Side Light; 3-26) Door Switch in Freezer

51
DISASSEMBLY AND REASSEMBLY
3-25) Side Light
Refrigerator Light
Part Name How To Do Descriptive Picture
1. Remove the cover Side
lamp(③) by a flat-blade
screwdriver.
2. Separate the Side lamp from the
case.
3. Disengage the housing.
3-26) Door Switch In Freezer
Door Switch In
Freezer
Part Name How To Do Descriptive Picture
1. Remove the freezer drawer bin
by using a flat-blade(-)
screwdriver.(Refer to the
picture)
2. Disconnect the housing
connector part.
