Samsung RF4287HARS/XAA - 3-23) Flex Zone Light; 3-24) Freezer Light

50
DISASSEMBLY AND REASSEMBLY
3-23) Flex Zone Light
Flex Zone Light
Part Name How To Do Descriptive Picture
1. Remove the cover Flex zone
lamp(①) by a flat-blade
screwdriver.
2. Disengage the housing.
3-24) Freezer Light
Freezer Light
Part Name How To Do Descriptive Picture
1. Remove the cover Freezer
lamp(②)like the way
disassembling the Flex zone
lamp.
2. Disengage the housing.
