Disassembly and Reassembly
4-8 Samsung Electronics
ΠREMOVE 4 SCREWS
´ REMOVE THE TERMINAL BOARD.
4-1-8 Ass’y Case Left Removal (2)
Fig. 4-8 Ass’y Case Left Removal (2)
