Samsung SCA20 - Page 41

Alignment and adjustment
Samsung Electronics 5-11
SCA20 SCA23 SCA25
MODE OSD DATA1 DATA2 DATA1 DATA2 DATA1 DATA2 NAME OF ADJUSTMENT
94 68 68 68 68 68 68 R INDOOR START VALUE OF W/B ADJUST
99 O2 O2 O2 O2 O2 O2 R OUTDOOR CONTROL UP/DOWN MARGIN
9A 83 83 83 83 83 83 R INDOOR CONTROL UP/DOWN MARGIN
9B O3 O3 O3 O3 O3 O3 B INDOOR CONTROL UP/DOWN MARGIN
9C 8D 8D 8D 8D 8D 8D B OUTDOOR CONTROL UP/DOWN MARGIN
9D OO OO OO OO OO OO INITIAL(POWER ON) R CTL START DATA
9E OO OO OO OO OO OO INITIAL(POWER ON) B CTL START VALUE
9F 6E 6E 6E 6E 6E 6E W/B TABLE MODE
A0 O2 O2 O2 O2 O2 O2 W/B SD/3+AEAVR-MAXDETE
A1 90 90 90 90 90 90 W/B CONTROL BOUNDARY
A2 A6 A6 A6 A6 A6 A6 W/B CTL STOP HALL OF MACRO AREA
A3 48 48 48 48 48 48 W/B OUTDOOR STOP HALL
A4 00 00 00 00 00 00 R/B CTL SPEED UP/DOWN MODE
A5 40 40 40 40 40 40 CINEMA AE-TARGET
A6 OO OO OO OO OO OO H NOISE THRESHOULD OF EIS
A7 20 20 20 20 20 20 W/B STABLE CONDITION
A8 05 05 05 05 05 05 R CONTROL UP/DOWN OF D Z00M
A9 05 05 05 05 05 05 B CONTROL UP/DOWN OF D Z00M
AA 0E 0E 0E 0E 0E 0E FOCUS RESET POSITION L
AB 11 11 11 11 11 11 FOCUS RESET POSITION H
AC 4B 4B 4B 4B 4B 4B ZOOM RESET POSITION L
AD 12 12 12 12 12 12 ZOOM RESET POSITION H
AE 83 83 83 83 83 83 ZOOM RESET DIFERRENCE
AF 40 40 40 40 40 40 AF FILTER1 DATA MAGNIFY RATO
B0 C0 C0 C0 C0 C0 C0 FILTER1 NOISE LEVEL(L) OF AREA1
B1 OO OO OO OO OO OO FILTER1 NOISE LEVEL(H) OF AREA1
B2 C0 C0 C0 C0 C0 C0 FILTER1 NOISE LEVEL(L) OF AREA2
B3 O2 O2 O2 O2 O2 O2 FILTER1 NOISE LEVEL(H) OF AREA2
B4 90 90 90 90 90 90 FILTER2 NOISE LEVEL(L) OF AREA1
B5 OO OO OO OO OO OO FILTER2 NOISE LEVEL(H) OF AREA1
B6 E0 E0 E0 E0 E0 E0 FILTER2 NOISE LEVEL(L) OF AREA2
B7 01 01 01 01 01 01 FILTER2 NOISE LEVEL(H) OF AREA2
BA 30 30 30 30 30 30 CHROMA SUPRESS START AGC
BE A0 A0 A0 A0 A0 A0 AE TAGET OF NEGA MODE(FADE IN)
BF 77 77 77 77 77 77 H/V ADJUST OF D ZOOM HEADER COMMEND
C0 2A 2A 2A 2A 2A 2A FADE LIMIT OF NEGA MODE
C1 28 28 28 28 28 28 DATA CONTROL BOUNDARY OF OUTDOOR
C2 24 24 24 24 24 24 NEGA MODE W/B R-CONTROL DATA
C3 A1 A1 A1 A1 A1 A1 FOCUS RETURN LOW BYTE
C4 15 15 15 15 15 15 FOCUS RETURN HIGH BYTE
C5 A0 A0 A0 A0 A0 A0 ZOOM RETURN LOW BYTE
C6 12 12 12 12 12 12 ZOOM RETURN HIGH BYTE
C7 O5 O5 O5 O5 O5 O5 LENS CHECK MARGIN (WIDE)
C8 12 12 12 12 12 12 LENS CHECK MARGIN (TELE)
C9 65 65 65 65 65 65 ADJUST MODE IRIS SETTING DATA
CA 7F 7F BF BF BF BF D ZOOM RAITO
CB O6 O6 O6 O6 O6 O6 AE UP/DOWN OF NEGA MODE BLC
CC 00 00 00 00 00 00 SETUP ADJUST ENABLE
D1 FF FF FF FF FF FF HALL AUTO CHECK
D2 FF FF FF FF FF FF AGC AUTO CHECK
D3 FF FF FF FF FF FF LENS CHECK OF PCB LINE
D4 FF FF FF FF FF FF GYRO SENSOR CHECK (H)
D5 FF FF FF FF FF FF GYRO SENSOR CHECK (V)
D7 01 01 01 01 01 01 ZOOM/FOCUS CHECK ENABLE
D8 20 20 20 20 20 20 VR ZOOM CENTER MARGEIN
D9 00 00 00 00 00 00 COLOR GAIN ADJUST
DA 7E 7E 7E 7E 7E 7E SETUP AUTO ADJUST
DB O8 O8 O8 O8 O8 O8 HALL CHECK THRESHOULD
DC 82 82 82 82 82 82 COLOR ADJUST TARGET VALUE
DD 89 89 89 89 89 89 HALL ADJUST GAIN TARGET
DE 4D 4D 4D 4D 4D 4D HALL ADJUST CENTER
