Disassembly and Reassembly
Samsung Electronics 4-3
ΠREMOVE THE ASS'Y CASE TOP BY GENTLY RELEASING 2 LOCKING
TABS WITH A SMALL SCREW DRIVER. (SEE DATAIL "A")
NOTE : WHEN REASSEMBLING, PUT THE 7 TABS
INTO THE SLOT WHILE SLIDING IT
AS SHOWN IN DETAIL "B".
2 LOCKING TABS
PRECISION
SCREW DRIVER
DETAIL "A"
DETAIL "B"
4-1-3 Ass’y Case Top Removal
Fig. 4-3 Ass’y Case Top Removal
