Disassembly and Reassembly
4-10 Samsung Electronics
ΠREMOVE 1 SCREW.
´ REMOVE THE ZOOM SWITCH.
ˇ REMOVE 2
SCREWS.
¨ REMOVE THE REAR BOARD.
4-1-10 Ass’y Rear Board Removal (2)
Fig. 4-10 Ass’y Rear Board Removal (2)
