Alignment and adjustment
Samsung Electronics 5-17
12. B-Y Negative Gain
1) Camera ÒE-EÓ, 3100¡K color bar chart.
2) Video(output) jack and register of EEPROM.
3) Connect video(output) jack to waveform monitor
input jack and monitor TV jack respectively.
4) Press the ÒBLC (MODE UP)/FADE
(MODE DOWN)Ó button so that the OSD state is
Ò37 CBGN XX XXÓ.
5) Aim the camera at a color bar chart illuminated at
1500 to 2000 lx.
6) Adjust the Ò + (DATA UP)/ - (DATA DOWN)Ó
button so that the yellow level is 50IRE.
7) Be sure to press the ÒSTART/STOP (CONFIRM)Ó
button to memorize setting.
8) The OSD shows ÒOK!Ó.
13. R-Y Positive Hue
1) Camera ÒE-EÓ, 3100¡K color bar chart.
2) Video(output) jack and register of EEPROM.
3) Connect video(output) jack to vectorscope input
jack and monitor TV jack respectively.
4) Press the ÒBLC (MODE UP)/FADE
(MODE DOWN)Ó button so that the OSD state is
Ò39 CBHN XX XXÓ.
5) Aim the camera at a color bar chart illuminated at
1500 to 2000 lx.
6) Adjust the Ò + (DATA UP)/ - (DATA DOWN)Ó
button so that the red vector is 104.
7) Be sure to press the ÒSTART/STOP (CONFIRM)Ó
button to memorize setting.
8) The OSD shows ÒOK!Ó.
RED VECTOR
104 DEG.
50IRE
14. R-Y Negative Hue
1) Camera ÒE-EÓ, 3100¡K color bar chart.
2) Video(output) jack and register of EEPROM.
3) Connect video(output) jack to vectorscope input
jack and monitor TV jack respectively.
4) Press the ÒBLC (MODE UP)/FADE
(MODE DOWN)Ó button so that the OSD state is
Ò38 CHGR XX XXÓ.
5) Aim the camera at a color bar chart illuminated at
1500 to 2000 lx.
6) Adjust the Ò + (DATA UP)/ - (DATA DOWN)Ó
button so that the cyan vector is 284.
7) Be sure to press the ÒSTART/STOP (CONFIRM)Ó
button to memorize setting.
8) The OSD shows ÒOK!Ó.
CYAN VECTOR
284 DEG.
