RP70 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
RP71 2007-000863 R-CHIP:4.3ohm,5%,1/10W,DA,TP,2012
RP72 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP73 2007-000863 R-CHIP:4.3ohm,5%,1/10W,DA,TP,2012
RP74 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
RP75 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
RP76 2007-000863 R-CHIP:4.3ohm,5%,1/10W,DA,TP,2012
RP77 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP78 2007-000100 R-CHIP;68Kohm,5%,1/16W,DA,TP,1608
RP79 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
RP80 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
RP81 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP85 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP87 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP89 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP90 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
RP91 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP93 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP95 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RS01 2007-000781 R-CHIP;33ohm,5%,1/10W,DA,TP,2012
RS02 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
RS03 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
RS04 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
RS05 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RS06 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
RS07 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RS08 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RS09 2007-001026 R-CHIP;560Kohm,5%,1/16W,DA,TP,1608
RS10 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RS11 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
RS13 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
RS14 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
RS15 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
RS16 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
RS17 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RS18 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RS19 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RS20 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
RS21 2007-001026 R-CHIP;560Kohm,5%,1/16W,DA,TP,1608
RS22 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RZ02 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
XP01 2801-001430 CRYSTAL-SMD;28.63636MHz,30ppm,28-ABL,7pF
XP03 2801-003491 CRYSTAL-UNIT;32MHz,50ppm,28-ABL,9.2pF,60
DC/DC CONBERTER BLOCK
C901 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C902 2203-000512 C-CERAMIC,CHIP;2.2uF,+80-20%,16V,Y5V,321
C903 2404-000128 C-TA,CHIP;10uF,20%,16V,-,TP,6032,-
C904 2203-001724 C-CERAMIC,CHIP;4.7UF,+80-20%,16V,Y5V,321
C905 2404-000120 C-TA,CHIP;10uF,20%,10V,-,TP,3528,-
C907 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C908 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C909 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C910 2404-000120 C-TA,CHIP;10uF,20%,10V,-,TP,3528,-
C912 2404-000120 C-TA,CHIP;10uF,20%,10V,-,TP,3528,-
C915 2404-000120 C-TA,CHIP;10uF,20%,10V,-,TP,3528,-
C916 2203-000512 C-CERAMIC,CHIP;2.2uF,+80-20%,16V,Y5V,321
C917 2404-000120 C-TA,CHIP;10uF,20%,10V,-,TP,3528,-
C918 2203-000481 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,32
C919 2203-000481 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,32
C920 2203-000481 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,32
C921 2203-000481 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,32
C922 2203-000512 C-CERAMIC,CHIP;2.2uF,+80-20%,16V,Y5V,321
C923 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C924 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C925 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C926 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C927 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C928 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C929 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1
C930 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608
C931 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1
C932 2203-001632 C-CERAMIC,CHIP;330pF,5%,50V,CH,1608,1.6m
C933 2203-001640 C-CERAMIC,CHIP;390PF,10%,50V,X7R,TP,1608
C934 2203-002220 C-CERAMIC,CHIP;56PF,5%,50V,CH,TP,1608,-
C935 2203-001632 C-CERAMIC,CHIP;330pF,5%,50V,CH,1608,1.6m
C936 2203-001640 C-CERAMIC,CHIP;390PF,10%,50V,X7R,TP,1608
C937 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C938 2203-001636 C-CERAMIC,CHIP;33pF,5%,50V,NPO,TP,1608,1
C940 2203-000512 C-CERAMIC,CHIP;2.2uF,+80-20%,16V,Y5V,321
C941 2203-001103 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,1608
C942 2203-001103 C-CERAMIC,CHIP;6.8nF,10%,50V,X7R,TP,1608
C943 2203-001609 C-CERAMIC,CHIP;22NF,10%,16V,X7R,TP,1608,
C944 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C945 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C946 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C949 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C950 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CN901 3711-002163 CONNECTOR-HEADER;3WALL,7P,1R,1.25mm,SMD-
D901 0404-000150 DIODE-SCHOTTKY;EC10QS04,40V,1A,SMD,TP
D902 0407-001013 DIODE-ARRAY;MA160A,80V,100mA,CX2,SOT-143
IC901 1203-000445 IC-POSI.FIXED REG.;14641,TO-220,3P,-,PLA
L901 2703-000402 INDUCTOR-SMD;1uH,20%,3.2x2.5x2.2mm
L902 2703-000408 INDUCTOR-SMD;3.3uH,20%,3.2x2.5x2.2mm
L903 2703-000408 INDUCTOR-SMD;3.3uH,20%,3.2x2.5x2.2mm
L904 2703-000414 INDUCTOR-SMD;22uH,20%,7x7x3.2mm
L905 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L906 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L907 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L908 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L909 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L910 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L911 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L912 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L913 2703-001194 INDUCTOR-SMD;100uH,20%,7x7x3.2mm
L914 2703-001194 INDUCTOR-SMD;100uH,20%,7x7x3.2mm
L915 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L916 2703-000399 INDUCTOR-SMD;100uH,10%,3.2x2.5x2.2mm
L917 2703-000399 INDUCTOR-SMD;100uH,10%,3.2x2.5x2.2mm
L918 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
L919 2703-000399 INDUCTOR-SMD;100uH,10%,3.2x2.5x2.2mm
Q901 0502-000432 TR-POWER;2SB1302-S,PNP,1.3W,SC-62,TP,14
Q902 0504-000113 TR-DIGITAL;DTC144EUA,NPN,200mW,47K-47K,S
Q903 0501-000172 TR-SMALL SIGNAL;2SB1121,PNP,500MW,PCP,TP
Q904 0501-000681 TR-SMALL SIGNAL;FP101,PNP,1.3W,PCP4,TP,1
Q905 0501-000681 TR-SMALL SIGNAL;FP101,PNP,1.3W,PCP4,TP,1
Q906 0501-000172 TR-SMALL SIGNAL;2SB1121,PNP,500MW,PCP,TP
Q907 0504-000113 TR-DIGITAL;DTC144EUA,NPN,200mW,47K-47K,S
Q908 0504-000107 TR-DIGITAL;DTA144EU,PNP,200mW,47K-47K,SC
Q909 0504-000107 TR-DIGITAL;DTA144EU,PNP,200mW,47K-47K,SC
Q910 0504-000113 TR-DIGITAL;DTC144EUA,NPN,200mW,47K-47K,S
R901 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R902 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R903 2007-001699 R-CHIP;120Kohm,0.5%,1/16W,DA,TP,1608
R904 2007-001694 R-CHIP;12Kohm,0.5%,1/16W,DA,TP,1608
R905 2007-007202 R-CHIP;51Kohm,0.5%,1/16W,DA,TP,1608
R906 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R907 2007-007204 R-CHIP;5.1Kohm,0.5%,1/16W,DA,TP,1608
R908 2007-000766 R-CHIP;330ohm,5%,1/10W,DA,TP,2012
R910 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
R911 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R912 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
R914 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R915 2007-000101 R-CHIP;82Kohm,5%,1/16W,DA,TP,1608
R916 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R917 2007-001643 R-CHIP;100Kohm,0.5%,1/16W,DA,TP,1608
R918 2007-001643 R-CHIP;100Kohm,0.5%,1/16W,DA,TP,1608
R919 2007-007203 R-CHIP;5.6Kohm,0.5%,1/16W,DA,TP,1608
R921 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
R922 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
R923 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R924 2007-001695 R-CHIP;22Kohm,0.5%,1/16W,DA,TP,1608
R925 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R926 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R927 2007-001114 R-CHIP;680Kohm,5%,1/16W,DA,TP,1608
R929 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
Loc.No
Part No Desc & Spec Remark
Loc.No
Part No Desc & Spec Remark
Electrical Parts List
Samsung Electronics
7-3
To Next Page
