R930 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
R931 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R932 2007-000081 R-CHIP;2.7Kohm,5%,1/16W,DA,TP,1608
R933 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
R934 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R935 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R936 2007-000655 R-CHIP;27Kohm,5%,1/16W,DA,TP 200
R937 2007-000101 R-CHIP;82Kohm,5%,1/16W,DA,TP,1608
R940 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R941 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R942 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R943 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R944 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R945 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R946 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R947 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
T901 AD26-20120E TRANS-CONVERTOR;REEL,-,CMS64(480UH);VP-A
SYSCON/SERVO BLOCK
B601 AC29-32001B FILTER-EMI BEAD:CB321611-TA SB 0.2OH,-,-
C401 2203-001567 C-CERAMIC,CHIP;10pF,0.5pF,50V,CH,1608,1.
C402 2203-001567 C-CERAMIC,CHIP;10pF,0.5pF,50V,CH,1608,1.
C403 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
C404 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C421 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C501 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C502 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C503 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C504 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608
C505 2203-001609 C-CERAMIC,CHIP;22NF,10%,16V,X7R,TP,1608,
C506 2203-001609 C-CERAMIC,CHIP;22NF,10%,16V,X7R,TP,1608,
C507 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C508 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C509 2203-000062 C-CERAMIC,CHIP;47NF,+80-20%,50V,Y5V,1608
C510 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C511 2203-000062 C-CERAMIC,CHIP;47NF,+80-20%,50V,Y5V,1608
C512 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C515 2203-001640 C-CERAMIC,CHIP;390PF,10%,50V,X7R,TP,1608
C516 2203-000929 C-CERAMIC,CHIP;470PF,10%,50V,X7R,1608,-,
C517 2203-000062 C-CERAMIC,CHIP;47NF,+80-20%,50V,Y5V,1608
C524 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C525 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
C526 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,1608,-,TP
C527 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C528 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C529 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C530 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C531 2404-000151 C-TA,CHIP;1uF,20%,16V,-,TP,3216,-
C532 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C533 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C534 2203-000062 C-CERAMIC,CHIP;47NF,+80-20%,50V,Y5V,1608
C535 2203-000888 C-CERAMIC,CHIP;4.7nF,10%,50V,X7R,TP,1608
C536 2203-001630 C-CERAMIC,CHIP;330nF,+80-20%,16V
C537 2203-002218 C-CERAMIC,CHIP;47NF,10%,16V,X7R,TP,1608,
C538 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C539 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C540 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
C541 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C542 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C543 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C544 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C545 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C546 2203-000199 C-CERAMIC,CHIP;100nF,+80-20%,50V,Z5U,TP,
C547 2402-000198 C-AL,SMD;47uF,20%,16V,GP,TP,6.3x5.4,-
C548 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C549 2404-000120 C-TA,CHIP;10uF,20%,10V,-,TP,3528,-
C550 2203-001559 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
C552 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C553 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C554 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C555 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C601 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C602 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C603 2402-001009 C-AL,SMD;100UF,20%,6.3V,GP,TP,5.3X5.3X5
C604 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C605 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C606 2404-000232 C-TA,CHIP;4.7uF,20%,10V,WT,3216,-,TP
C608 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C609 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-
C610 2203-000626 C-CERAMIC,CHIP;22pF,5%,50V,NPO,TP,1608,-
C611 2203-000384 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,1608,-
C612 2203-000384 C-CERAMIC,CHIP;15pF,5%,50V,NPO,TP,1608,-
C613 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C614 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C615 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
C616 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C617 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C618 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C625 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
C626 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
C628 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
CN501 3710-001301 CONNECTOR-SOCKET;48P,2R,0.8mm,SMD-S,SN
CN601 3710-001110 CONNECTOR-SOCKET;18P,2R,0.8MM,SMD-S,AU
CN602 3708-001130 CONNECTOR-FPC/FC/PIC;12P,0.5mm,SMD-S,SN
D402 0407-000115 DIODE-ARRAY;DAN202U,80V,100mA,CA
IC401 1204-001146 IC-OSD PROCESSOR;BU6251FV,SOP,20P,240MIL
IC421 1002-001070 IC-D/A CONVERTER;M62353GP,8BIT,SOP,16P,-
IC501 AC14-12005J IC-LOGIC;KA8322,QFP,-
IC502 1003-001012 IC-MOTOR DRIVER;LB1950,SOP,30P,300MIL,SI
IC503 1003-001020 IC-MOTOR DRIVER;LB1951,SOP,24P,-,SINGLE,
IC504 1003-001146 IC-MOTOR DRIVER;LB1843VL,SOP,20P,-,-,800
IC601 AD09-10451Y IC-MCU;CXP87240A-132Q,100P,QFP,SCA23,
IC602 1203-001123 IC-VOLTAGE REGULATOR;8420,SOP,8P,216MIL,
L401 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L402 2703-000372 INDUCTOR-SMD;56uH,5%,2.5x2x1.8mm
L421 2703-000397 INDUCTOR-SMD;33uH,10%,2.5x2x1.8mm
L601 2703-000399 INDUCTOR-SMD;100uH,10%,3.2x2.5x2.2mm
Q401 0504-000105 TR-DIGITAL;DTA114EU,PNP,200MW,10K-10K,SC
Q501 0501-000172 TR-SMALL SIGNAL;2SB1121,PNP,500MW,PCP,TP
Q502 0504-000110 TR-DIGITAL;DTC114EU,NPN,200mW,10K-10Kohm
Q602 0504-000194 TR-DIGITAL;DTC124EU,NPN,200MW,22K-22K,SC
Q604 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
Q605 0504-000107 TR-DIGITAL;DTA144EU,PNP,200mW,47K-47K,SC
R401 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R402 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R403 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R404 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R405 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R406 2007-000080 R-CHIP;2Kohm,5%,1/16W,DA,TP,1608
R407 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R408 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
R409 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R410 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R412 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
R413 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R416 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
R501 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
R502 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R503 2007-000065 R-CHIP;2.2Mohm,5%,1/16W,DA,TP,1608
R504 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R505 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
R506 2007-000098 R-CHIP;56Kohm,5%,1/16W,DA,TP,1608
R507 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R508 2007-001114 R-CHIP;680Kohm,5%,1/16W,DA,TP,1608
R509 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R510 2007-000123 R-CHIP;1.5Kohm,5%,1/16W,DA,TP,1608
R511 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
R512 2007-000087 R-CHIP;6.8Kohm,5%,1/16W,DA,TP,1608
R513 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
R514 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608
R515 2007-000093 R-CHIP;20Kohm,5%,1/16W,DA,TP,1608
R516 2007-000093 R-CHIP;20Kohm,5%,1/16W,DA,TP,1608
R517 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
R518 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
R519 2007-000458 R-CHIP;18Kohm,5%,1/16W,DA,TP,1608
R523 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
Loc.No
Part No Desc & Spec Remark
Loc.No
Part No Desc & Spec Remark
7-4
Samsung Electronics
Electrical Parts List
