AD44-30100E ADAPTER-AC POWER;110-220V,60HZ,-,-,-,AA-
C10 2306-000113 C-FILM,MPPF;100nF,20%,250V,TP,6.5X5.5X3.
C11 2201-000808 C-CERAMIC,DISC;2.2nF,10%,400V,Y5P,12x7.5
C12 2201-000808 C-CERAMIC,DISC;2.2nF,10%,400V,Y5P,12x7.5
C13 2401-001567 C-AL;47uF,20%,400V,WT,-,18x20,10mm
C14 2201-000808 C-CERAMIC,DISC;2.2nF,10%,400V,Y5P,12x7.5
C15 2201-000808 C-CERAMIC,DISC;2.2nF,10%,400V,Y5P,12x7.5
C16 2301-000140 C-FILM,PEF;10nF,10%,630V,16.5X9.5X5.7X,1
C17 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012,-
C18 2401-002180 C-AL;2.2UF,20%,50V,GP,TP,5X11,5MM
C19 2203-000840 C-CERAMIC,CHIP;390PF,5%,50V,NPO,TP,2012,
C20 2203-001576 C-CERAMIC,CHIP;150NF,+80-20%,50V,Z5U,TP,
C21 2401-001184 C-AL;33UF,20%,35V,GP,-,6X11,5MM
C22 2401-002168 C-AL;100UF,20%,50V,GP,TP,10X12.5,5M
C23 2203-000199 C-CERAMIC,CHIP;100nF,+80-20%,50V,Z5U,TP,
C50 2401-001591 C-AL;47uF,20%,6.3V,GP,5x7,2.5mm,
C51 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012,-
C52 2203-001537 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,2012,-
C53 2401-001878 C-AL;1000UF,20%,16V,GP,BK,10X20MM,5
C54 2401-001374 C-AL;470UF,20%,16V,WT,TP,10X12.5,2.
C55 2203-000199 C-CERAMIC,CHIP;100nF,+80-20%,50V,Z5U,TP,
C56 2203-000260 C-CERAMIC,CHIP;10nF,10%,50V,X7R,TP,2012,
C57 2401-001917 C-AL;1UF,20%,50V,-,TP,5X7MM,5
C59 2401-001952 C-AL;4.7UF,20%,50V,-,TP,6.3X7,5
C60 61453-131-105 C-CERAMIC.CHIP;GRM42-6Y5V105Z16 TAPG
C61 2203-000199 C-CERAMIC,CHIP;100nF,+80-20%,50V,Z5U,TP,
C62 B1100-0674 C-CERAMIC,CHIP;CK 73 Y5V 16V T 685-Z C32
C64 2201-000913 C-CERAMIC,DISC;100NF,+80-20%,50V,Y5V,TP,
C65 2202-000780 C-CERAMIC,MLC-AXIAL;100NF,+80-20%,50V,Y5
C66 2203-000199 C-CERAMIC,CHIP;100nF,+80-20%,50V,Z5U,TP,
C67 2203-000199 C-CERAMIC,CHIP;100nF,+80-20%,50V,Z5U,TP,
CL10 64709-084-770 CLIP-FUSE;RBP4-1 1/2H 3A 0.4T
CL11 64709-084-770 CLIP-FUSE;RBP4-1 1/2H 3A 0.4T
D10 0402-000386 DIODE-BRIDGE;S1WB60,600V,1A,DIP-4
D11 0402-000391 DIODE-RECTIFIER;ERA22-10,1000V,500MA,MSR
D12 0401-000170 DIODE-SWITCHING;MA110,40V,100mA,-,3nS,SM
D13 0403-000646 DIODE-ZENER;RD20SB,20V,18.8-21.14V,200mW
D14 0403-000648 DIODE-ZENER;RD4.7SB,4.7V,4.4-4.92,200mW,
D15 0403-000647 DIODE-ZENER;RD24SB,24V,22.86-25.66V,200m
D16 0402-000391 DIODE-RECTIFIER;ERA22-10,1000V,500MA,MSR
D17 0402-000391 DIODE-RECTIFIER;ERA22-10,1000V,500MA,MSR
D51 0404-000135 DIODE-SCHOTTKY;ESAC85M-009,90V,10A,TO-22
D52 0402-000165 DIODE-RECTIFIER;1N5819,40V,1A,DO-41,TP
D53 0407-000114 DIODE-ARRAY;DAN202K,80V,100mA,CA2-3,SOT-
D54 0407-000116 DIODE-ARRAY;DAP202K,80V,100mA,CK2-3,SOT
D55 0401-000170 DIODE-SWITCHING;MA110,40V,100mA,-,3nS,SM
D57 0403-000649 DIODE-ZENER;RD5.1S,5.1V,4.96-5.22V,200mW
F10 A3065-0154 FUSE;FST 250V 1.25A 5X20MM UL/CSA
IC11 AC14-12011C IC;FA5304S,SOP,8P TAPE
IC12 B4161-0037 PHOTO-COUPLER;TLP621-GR ST
IC51 1201-000203 IC-OP AMP;3414,SOP,8P,300MIL,DUAL,-,PLAS
IC52 AC14-12006R IC;TK11640N,TO-92S,3P TAPE
J51 B3040-0068 JACK-DC;PI3 HEC0740-01-010 3P
L10 AC27-32001F COIL-LINE FILTER;BSF-2123,20MH,2OHM,ST,-
L11 A1247-0053 FILTER-EMI BEAD;BFS3565A0L SB 100OHM/100
L51 2702-000112 INDUCTOR-RADIAL;10uH,5%,6x6.4mm
L52 AC27-12001F COIL-CHOKE;100UH,J,-,-,-,100UH-J RA 1KHZ
LED51 B4150-0287 LED-DISPLAY;LN086WP38 ORG/GRN PI1.8
PCB01 66029-1084-00 P.C.B-AA-E2N;FR4 CS95 T1.6 W139 L62
PWR01 AC39-12022N POWER-CORD;EP2,SPT-2,BLK,YH396,1.83MT
Q10 0505-001044 FET-SILICON;SSS3N80,N,800V,1.8A,5ohm,35W
Q51 0502-000399 TR-POWER;2SB1127S,PNP,-25V,-20V,-5A,1W,
Q52 62129-101-110 TRANSISTOR.CHIP;KSR 1102 (REEL)
Q53 0502-000431 TR-POWER;2SB1203S,PNP,-60V,-50V,-5A,1W,
Q54 62129-101-110 TRANSISTOR.CHIP;KSR 1102 (REEL)
Q55 0504-000158 TR-DIGITAL;KSR2104,PNP,200MW,47K-47K,SOT
Q56 0504-000158 TR-DIGITAL;KSR2104,PNP,200MW,47K-47K,SOT
Q57 0504-000158 TR-DIGITAL;KSR2104,PNP,200MW,47K-47K,SOT
R01 2007-000029 R-CHIP;0ohm,5%,1/10W,DA,TP,2012
R02 2007-000029 R-CHIP;0ohm,5%,1/10W,DA,TP,2012
R03 2007-000029 R-CHIP;0ohm,5%,1/10W,DA,TP,2012
R04 2007-000029 R-CHIP;0ohm,5%,1/10W,DA,TP,2012
R05 2007-000033 R-CHIP;0ohm,5%,1/8W,DA,TP,3216
R06 2007-000033 R-CHIP;0ohm,5%,1/8W,DA,TP,3216
R11 2002-000322 R-COMPOSITION;2.7Mohm,10%,1/2W,AA,TP,3.5
R12 A1014-0079 R-CEMENT;RWC 2W I 3R3-J ST ABCO
R13 2001-001000 R-CARBON;82Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R14 2001-001000 R-CARBON;82Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R15 2007-001212 R-CHIP;82Kohm,5%,1/8W,DA,TP,3216
R16 2001-001000 R-CARBON;82Kohm,5%,1/8W,AA,TP,1.8x3.2mm
R17 2003-000307 R-METAL OXIDE;47Kohm,5%,2W,AD,TP,6x16mm
R19 2003-000111 R-METAL OXIDE;0.47ohm,5%,1W,AD,TP,4.3x12
R20 2007-000572 R-CHIP;220ohm,5%,1/10W,DA,TP,2012
R21 2007-000781 R-CHIP;33ohm,5%,1/10W,DA,TP,2012
R22 2007-000248 R-CHIP;1.5Mohm,5%,1/10W,DA,TP,2012
R24 2007-000781 R-CHIP;33ohm,5%,1/10W,DA,TP,2012
R25 2007-001177 R-CHIP;8.2Kohm,5%,1/10W,DA,TP,2012
R51 2007-000312 R-CHIP;10ohm,5%,1/8W,DA,TP,3216
R52 2007-000515 R-CHIP;2.7Kohm,1%,1/10W,DA,TP,2012
R53 2007-000218 R-CHIP;1.2Kohm,1%,1/10W,DA,TP,2012
R54 2007-000639 R-CHIP;270ohm,1%,1/10W,DA,TP,2012
R55 2007-000282 R-CHIP;100Kohm,5%,1/10W,DA,TP,2012
R56 2007-000572 R-CHIP;220ohm,5%,1/10W,DA,TP,2012
R57 2007-000518 R-CHIP;2.7Kohm,5%,1/10W,DA,TP,2012
R58 2007-000282 R-CHIP;100Kohm,5%,1/10W,DA,TP,2012
R59 2007-000361 R-CHIP;12ohm,5%,1/10W,DA,TP,2012
R60 2007-000928 R-CHIP;470ohm,1%,1/10W,DA,TP,2012
R61 2007-000218 R-CHIP;1.2Kohm,1%,1/10W,DA,TP,2012
R62 2007-000868 R-CHIP;4.7Kohm,1%,1/10W,DA,TP,2012
R63 2007-000868 R-CHIP;4.7Kohm,1%,1/10W,DA,TP,2012
R64 2007-000658 R-CHIP;27ohm,5%,1/10W,DA,TP,2012
R65 2003-000102 R-METAL OXIDE;0.1ohm,5%,1W,AD,TP,4.3x12m
R66 2007-000355 R-CHIP;12Kohm,5%,1/10W,DA,TP,2012
R67 2007-000221 R-CHIP;1.2Kohm,5%,1/10W,DA,TP,2012
R68 2007-000493 R-CHIP;2.2Kohm,5%,1/10W,DA,TP,2012
R69 2007-000931 R-CHIP;470ohm,5%,1/10W,DA,TP,2012
R70 B1004-0442 R-METAL OXIDE;RS 3W N 43-J ERG3SJ430H
R71 2007-000300 R-CHIP;10Kohm,5%,1/10W,DA,TP,2012
R72 2007-000300 R-CHIP;10Kohm,5%,1/10W,DA,TP,2012
R73 2007-000468 R-CHIP;1Kohm,5%,1/10W,DA,TP,2012
R74 B1004-0442 R-METAL OXIDE;RS 3W N 43-J ERG3SJ430H
R75 2007-000409 R-CHIP;15Kohm,5%,1/10W,DA,TP,2012
R76 2007-000409 R-CHIP;15Kohm,5%,1/10W,DA,TP,2012
R77 2007-000300 R-CHIP;10Kohm,5%,1/10W,DA,TP,2012
R78 2007-000409 R-CHIP;15Kohm,5%,1/10W,DA,TP,2012
R79 2007-000300 R-CHIP;10Kohm,5%,1/10W,DA,TP,2012
R80 2007-000822 R-CHIP;390ohm,5%,1/10W,DA,TP,2012
R81 2007-000409 R-CHIP;15Kohm,5%,1/10W,DA,TP,2012
R82 2007-000518 R-CHIP;2.7Kohm,5%,1/10W,DA,TP,2012
R83 2007-000822 R-CHIP;390ohm,5%,1/10W,DA,TP,2012
R84 2007-000653 R-CHIP;27Kohm,5%,1/10W,DA,TP,2012
R85 2007-000409 R-CHIP;15Kohm,5%,1/10W,DA,TP,2012
R86 2007-000653 R-CHIP;27Kohm,5%,1/10W,DA,TP,2012
R87 2003-000146 R-METAL OXIDE;100ohm,5%,1W,AD,TP,4.3x12m
R90 2007-000950 R-CHIP;47ohm,5%,1/8W,DA,TP,3216
R91 2007-000950 R-CHIP;47ohm,5%,1/8W,DA,TP,3216
R92 2007-000950 R-CHIP;47ohm,5%,1/8W,DA,TP,3216
R93 2007-000950 R-CHIP;47ohm,5%,1/8W,DA,TP,3216
R94 2007-000653 R-CHIP;27Kohm,5%,1/10W,DA,TP,2012
R95 2007-000221 R-CHIP;1.2Kohm,5%,1/10W,DA,TP,2012
R96 2007-000267 R-CHIP;1.8Kohm,5%,1/10W,DA,TP,2012
R97 2001-000429 R-CARBON;1Kohm,5%,1/8W,AA,TP,1.8x3.2mm
SW51 3404-000239 SWITCH-TACT;15V,20mA,130+-40gf,6x6mm,-
T10 AC26-80001F TRANS-POWER;EI25X19,AC90/260V,50Hz,-
W10 3711-000178 CONNECTOR-HEADER;1WALL,2P,1R,3.96mm,STRA
XT51 64539-102-012 CERAMIC RESONATOR;FCR 4.0MC5
IC53 AD09-12001F IC-MICOM;TMP47C241N,STICK,28P
148 AD90-10822G ASSY-TERMINAL;A2-P/J,SAMSUNG
CN001 AD39-20826B LEAD CONNECTOR-ASSY;TP,51021,53023,7P,13
D001 0402-001166 DIODE-RECTIFIER;RL203,200V,2.0A,DO-15,TP
J001 AD37-22001B JACK-DC POWER;4.4MM,DDAE-9724,3P,BULK,BL
JP001 3811-000389 WIRE-NO SHEATH CU;SPCW,300V,52.4mm,1/0.5
PS001 3601-001089 FUSE-PC BOARD;125V,2A,SLOW-BLOW,CERAMIC,
Loc.No
Part No Desc & Spec Remark
Loc.No
Part No Desc & Spec Remark
7-8
Samsung Electronics
Electrical Parts List
