125 AD90-10831A ASSY-FRONT BOARD;VP-A22,FRONT(MOD-GYRO) SCA23/25
C801 2401-002206 C-AL;47UF,20%,6.3V,GP,TP,5X7,5MM
CN802 3711-000779 CONNECTOR-HEADER;BOX,2P,1R,1.25MM,ANGLE,
GY801 AC39-22018S SENSOR;-,-,-,ENC-05DA,-
GY802 AC39-22018T SENSOR;-,-,-,ENC-05DB,-
RE801 AD59-60060E MODULE-REMOCON;DP,PNA4612M00XC,38KHz,940
112 AD59-10538A UNIT-REAR;VP-A20,-
J851 3722-001202 JACK-PHONE;7P,3.6MM,AG,YEL,NO
SW851 3408-000298 SWITCH-SLIDE;5V,1A,-,-
VR851 2101-001018 VR-ROTARY;50KOHM,30%,0.03W,TOP
CN851 3711-003315 CONNECTOR-HEADER;BOX,18P,2R,0.8MM,SMD-A,
R851 2007-000277 R-CHIP;100Kohm,1%,1/10W,DA,TP,2012
R852 2007-000931 R-CHIP;470ohm,5%,1/10W,DA,TP,2012
R853 2007-000454 R-CHIP;18Kohm,1%,1/10W,DA,TP,2012
R854 2007-000771 R-CHIP;33Kohm,1%,1/10W,DA,TP,2012
R855 2007-000771 R-CHIP;33Kohm,1%,1/10W,DA,TP,2012
R856 2007-001124 R-CHIP;68Kohm,1%,1/10W,DA,TP,2012
R857 2007-000931 R-CHIP;470ohm,5%,1/10W,DA,TP,2012
R858 2007-000454 R-CHIP;18Kohm,1%,1/10W,DA,TP,2012
R859 2007-000771 R-CHIP;33Kohm,1%,1/10W,DA,TP,2012
R860 2007-000771 R-CHIP;33Kohm,1%,1/10W,DA,TP,2012
SW852 3404-000241 SWITCH-TACT;15V,20MA,-,6.8X6.2MM,-
SW853 3404-000241 SWITCH-TACT;15V,20MA,-,6.8X6.2MM,-
SW854 3404-000241 SWITCH-TACT;15V,20MA,-,6.8X6.2MM,-
SW855 3404-000241 SWITCH-TACT;15V,20MA,-,6.8X6.2MM,-
SW856 3404-000241 SWITCH-TACT;15V,20MA,-,6.8X6.2MM,-
SW857 3404-000241 SWITCH-TACT;15V,20MA,-,6.8X6.2MM,-
SW858 3404-000241 SWITCH-TACT;15V,20MA,-,6.8X6.2MM,-
SW859 3404-000241 SWITCH-TACT;15V,20MA,-,6.8X6.2MM,-
SW860 3404-000241 SWITCH-TACT;15V,20MA,-,6.8X6.2MM,-
SW861 3404-000241 SWITCH-TACT;15V,20MA,-,6.8X6.2MM,-
SW862 3404-000241 SWITCH-TACT;15V,20MA,-,6.8X6.2MM,-
187 AD90-10823U ASSY-CCD BOARD;A2-PJ,NTSC
CC01 2203-000140 C-CERAMIC,CHIP;1.5nF,10%,50V,X7R,1608,-,
CC02 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC03 2404-000190 C-TA,CHIP;22uF,20%,16V,-,5832,-,TP
CC04 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC05 2404-000130 C-TA,CHIP;10uF,20%,20V,-,6032,-,TP
CC06 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CC07 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CNC01 3711-003315 CONNECTOR-HEADER;BOX,18P,2R,0.8MM,SMD-A,
DC01 0401-000170 DIODE-SWITCHING;MA110,40V,100mA,-,3nS,SM
DC02 0401-000170 DIODE-SWITCHING;MA110,40V,100mA,-,3nS,SM
QC01 0505-000180 FET-SILICON;2SK1070PIETR,-,150MW,SOT
RC01 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RC02 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RC03 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
RC05 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RC06 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
613 AD90-10823T ASSY-CVF BOARD;A2-PJ,NTSC SCA23/25
CE01 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CE03 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CE04 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CE05 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CE09 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE10 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE11 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE12 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CE13 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE14 2404-000107 C-TA,CHIP;100nF,20%,35V,-,TP,3216,-
CE15 2404-000107 C-TA,CHIP;100nF,20%,35V,-,TP,3216,-
CE16 2203-001634 C-CERAMIC,CHIP;33nF,10%,50V,X7R,TP,1608,
CE17 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE18 2404-000153 C-TA,CHIP;1uF,20%,20V,-,3216,-,TP
CE20 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE21 2404-000153 C-TA,CHIP;1uF,20%,20V,-,3216,-,TP
CE22 2404-000204 C-TA,CHIP;3.3uF,20%,10V,-,3216,-,TP
CE23 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CE25 2404-000153 C-TA,CHIP;1uF,20%,20V,-,3216,-,TP
CE26 2404-000251 C-TA,CHIP;470nF,20%,35V,-,3216,-,TP
CE27 2404-000204 C-TA,CHIP;3.3uF,20%,10V,-,3216,-,TP
CE28 2203-000715 C-CERAMIC,CHIP;3.3nF,10%,50V,X7R,1608,-,
CE29 2203-001607 C-CERAMIC,CHIP;220pF,5%,50V,CH,1608,1.6m
CE30 2203-000257 C-CERAMIC,CHIP;10nF,10%,50V,X7R,1608,-,T
CE31 2203-001683 C-CERAMIC,CHIP;68PF,5%,50V,CH,TP,1608,1.
CE32 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CE33 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE34 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CE35 2203-001656 C-CERAMIC,CHIP;470pF,5%,50V,CH,1608,1.6m
CE36 2203-000491 C-CERAMIC,CHIP;2.2nF,10%,50V,X7R,TP,1608
CE37 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CE38 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CE39 2203-000477 C-CERAMIC,CHIP;1uF,+80-20%,16V,Y5V,TP,20
CE40 2404-000153 C-TA,CHIP;1uF,20%,20V,-,3216,-,TP
CE42 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE43 2404-000112 C-TA,CHIP;100uF,20%,6.3V,WT,7343,-,TP
CE44 2404-000153 C-TA,CHIP;1uF,20%,20V,-,3216,-,TP
CE45 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CE46 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CE50 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CE51 2203-001556 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CNE01 3708-001143 CONNECTOR-FPC/FC/PIC;12P,0.8mm,SMD-A,SN
CNE02 3708-000514 CONNECTOR-FPC/FC/PIC;16P,0.5MM,SMD-S,SN
CNE03 3711-002613 CONNECTOR-HEADER;3WALL,3P,1R,1.25MM,SMD-
DE01 0405-000123 DIODE-VARACTOR;1T369,34V,10nA,DSM,TP
DE02 0401-000170 DIODE-SWITCHING;MA110,40V,100mA,-,3nS,SM
DE03 0401-000170 DIODE-SWITCHING;MA110,40V,100mA,-,3nS,SM
DE04 0401-000170 DIODE-SWITCHING;MA110,40V,100mA,-,3nS,SM
ICE01 1003-001104 IC-LCD DRIVER;CXA2503R,QFP,64P,400MIL,TR
ICE02 AC11-12001G IC-EEPROM;AT24C02N-10SC,QFP,-
ICE03 AD14-10001C IC-AMP;NJM2904V,SSOP,OP-AMP
ICE04 0801-000301 IC-CMOS LOGIC;7W04,INVERTER,SOP,8P,150MI
ICE05 0801-000301 IC-CMOS LOGIC;7W04,INVERTER,SOP,8P,150MI
ICE06 0801-002001 IC-CMOS LOGIC;7W74,D FLIP FLOP,SOP,8P,12
LE03 2703-001493 INDUCTOR-SMD;10uH,5%,2.5x2.0x1.8
LE04 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
LE05 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
LE06 2703-000398 INDUCTOR-SMD;10UH,10%,3.2X2.5X2.2MM
LE07 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
QE01 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
QE02 0506-000138 TR-ARRAY;IMZ1,NPN/PNP,1,50V,40V,100MA,3
QE03 0504-000211 TR-DIGITAL;DTC143TU,NPN,200MW,4.7K,SC-70
QE04 0504-000211 TR-DIGITAL;DTC143TU,NPN,200MW,4.7K,SC-70
QE05 0504-000211 TR-DIGITAL;DTC143TU,NPN,200MW,4.7K,SC-70
QE06 0504-000211 TR-DIGITAL;DTC143TU,NPN,200MW,4.7K,SC-70
QE07 0504-000211 TR-DIGITAL;DTC143TU,NPN,200MW,4.7K,SC-70
QE08 0501-000218 TR-SMALL SIGNAL;2SC4081,NPN,200mW,UMT,TP
RE01 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RE02 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
RE03 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RE04 2007-000130 R-CHIP;39Kohm,5%,1/16W,DA,TP,1608
RE07 2007-000091 R-CHIP;12Kohm,5%,1/16W,DA,TP,1608
RE08 2007-000637 R-CHIP;270Kohm,5%,1/16W,DA,TP,1608
RE09 2007-000106 R-CHIP;220Kohm,5%,1/16W,DA,TP,1608
RE10 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
RE11 2007-000094 R-CHIP;22Kohm,5%,1/16W,DA,TP,1608
RE12 2007-000655 R-CHIP;27Kohm,5%,1/16W,DA,TP 200
RE13 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RE14 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RE16 2007-001157 R-CHIP;750ohm,5%,1/16W,DA,TP,160
RE17 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RE18 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RE19 2007-000134 R-CHIP;33Kohm,5%,1/16W,DA,TP,1608
RE20 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RE21 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RE22 2007-000614 R-CHIP;24Kohm,1%,1/16W,DA,TP,1608
RE23 2007-000239 R-CHIP;1.5Kohm,1%,1/16W,DA,TP,1608
RE24 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
RE25 2007-000455 R-CHIP;18Kohm,1%,1/16W,DA,TP,1608
RE26 2007-000614 R-CHIP;24Kohm,1%,1/16W,DA,TP,1608
RE27 2007-000683 R-CHIP;3.3Kohm,1%,1/16W,DA,TP,1608
RE28 2007-000067 R-CHIP;15Kohm,1%,1/16W,DA,TP,1608
RE29 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
Loc.No
Part No Desc & Spec Remark
Loc.No
Part No Desc & Spec Remark
Electrical Parts List
Samsung Electronics
7-9
