Samsung Electronics 7-17
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
RP34 2007-000096 R-CHIP;30Kohm,5%,1/16W,DA,TP,1608
RP35 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP36 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RP37 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP38 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP39 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP40 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RP41 2007-000079 R-CHIP;1.8Kohm,5%,1/16W,DA,TP,1608
RP42 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP43 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP46 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP47 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP48 2007-000863 R-CHIP;4.3OHM,5%,1/10W,DA,TP,2012
RP50 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP52 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP53 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP54 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP59 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
RP61 2007-000052 R-CHIP;10Kohm,1%,1/16W,DA,TP,1608
RP63 2007-000583 R-CHIP;22Kohm,1%,1/16W,DA,TP,1608
RP65 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP71 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP72 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP73 2007-000122 R-CHIP;1.2Kohm,5%,1/16W,DA,TP,1608
RP74 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
RP75 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RP76 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RP77 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP78 2007-000098 R-CHIP;56Kohm,5%,1/16W,DA,TP,1608
RP79 2007-000098 R-CHIP;56Kohm,5%,1/16W,DA,TP,1608
RP80 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RP81 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP82 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP84 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
RP85 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP88 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
RP89 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
SW601 3404-001083 SWITCH-TACT;12V,50mA,200gf,6x7.4x2.3mm,S
SW603 3404-001083 SWITCH-TACT;12V,50mA,200gf,6x7.4x2.3mm,S
SW604 3404-001083 SWITCH-TACT;12V,50mA,200gf,6x7.4x2.3mm,S
SW605 3404-001083 SWITCH-TACT;12V,50mA,200gf,6x7.4x2.3mm,S
SW606 3404-001083 SWITCH-TACT;12V,50mA,200gf,6x7.4x2.3mm,S
T901 AD26-00001A TRANS-POWER;CST063,15V,-7.5V,A3-PJ(C) CVF
T901 AD26-20120N TRANS-CONVERTOR;REEL,0.018mH +/-30%,CST0 EVF
X601 2801-003239 CRYSTAL-SMD;11.71875MHz,50ppm,28-ABL,13p PAL
X601 2801-003242 CRYSTAL-SMD;11.895104MHz,50ppm,28-ABL,13 NTSC
XP01 2801-001428 CRYSTAL-SMD;28.375MHz,30ppm,28-ABL,7pF,6 PAL
XP01 2801-001430 CRYSTAL-SMD;28.63636MHz,30ppm,28-ABL,7pF NTSC
XP03 2801-003710 CRYSTAL-SMD;12MHz,100ppm,28-ABN,9.2pF,60
XP04 2801-000258 CRYSTAL-UNIT;32.768KHz,20ppm,28-AAW,12.5
RP139 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608
RP14 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP140 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
RP141 2007-000125 R-CHIP;3.9Kohm,5%,1/16W,DA,TP,1608
RP142 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RP144 2007-000763 R-CHIP;330ohm,1%,1/16W,DA,TP,1608
RP145 2007-000763 R-CHIP;330ohm,1%,1/16W,DA,TP,1608
RP146 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
RP147 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
RP148 2007-000309 R-CHIP;10ohm,5%,1/16W,DA,TP,1608
RP149 2007-000029 R-CHIP;0OHM,5%,1/10W,DA,TP,2012
RP15 2007-000121 R-CHIP;820ohm,5%,1/16W,DA,TP,1608
RP152 2007-000084 R-CHIP;4.7Kohm,5%,1/16W,DA,TP,1608
RP153 2007-000098 R-CHIP;56Kohm,5%,1/16W,DA,TP,1608
RP154 2007-000763 R-CHIP;330ohm,1%,1/16W,DA,TP,1608
RP155 2007-000119 R-CHIP;560ohm,5%,1/16W,DA,TP,1608
RP156 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RP157 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608
RP158 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP16 2007-000109 R-CHIP;1Mohm,5%,1/16W,DA,TP,1608
RP160 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RP161 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP165 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP166 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP167 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP168 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP169 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP17 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608
RP170 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP171 2007-000078 R-CHIP;1Kohm,5%,1/16W,DA,TP,1608
RP172 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP173 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP174 2007-000124 R-CHIP;2.2Kohm,5%,1/16W,DA,TP,1608
RP176 2007-000402 R-CHIP;150ohm,5%,1/16W,DA,TP,1608
RP18 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP19 2007-000863 R-CHIP;4.3OHM,5%,1/10W,DA,TP,2012
RP20 2007-000863 R-CHIP;4.3OHM,5%,1/10W,DA,TP,2012
RP21 2007-000863 R-CHIP;4.3OHM,5%,1/10W,DA,TP,2012
RP22 2007-000863 R-CHIP;4.3OHM,5%,1/10W,DA,TP,2012
RP23 2007-000074 R-CHIP;100ohm,5%,1/16W,DA,TP,1608
RP24 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
RP25 2007-000076 R-CHIP;330ohm,5%,1/16W,DA,TP,1608
RP26 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP27 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608
RP28 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP29 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP30 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP31 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP32 2007-000102 R-CHIP;100Kohm,5%,1/16W,DA,TP,1608
RP33 2007-000113 R-CHIP;33ohm,5%,1/16W,DA,TP,1608
