Samsung Electronics7-18
Electrical Parts List
Loc. No Part No Desc & Spec Remark Loc. No Part No Desc & Spec Remark
CG27 2203-000236 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
CG28 2203-001630 C-CERAMIC,CHIP;330nF,+80-20%,16V,Y5V,TP,
CG29 2203-000236 C-CERAMIC,CHIP;100pF,5%,50V,NPO,TP,1608,
CG30 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CG31 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CG32 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CG33 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CG34 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CG35 2203-000332 C-CERAMIC,CHIP;12pF,5%,50V,NPO,TP,1608,-
CG36 2203-000332 C-CERAMIC,CHIP;12pF,5%,50V,NPO,TP,1608,-
CG37 2203-002793 C-CERAMIC,CHIP;1uF,+80-20%,25V,Y5V,TP,20
CN890 AD39-00010A LEAD CONNECTOR-ASSY;-,35023,51021,12P,70 STEREO
CN890 AD39-20826V LEAD CONNECTOR-ASSY;-,35023,51021,8P,70M MONO
CN891 3711-000779 CONNECTOR-HEADER;BOX,2P,1R,1.25MM,ANGLE, MONO
CN891 3711-000922 CONNECTOR-HEADER;BOX,4P,1R,1.25mm,SMD-A, STEREO
CN893 3711-000456 CONNECTOR-HEADER;3WALL,4P,1R,1.25mm,SMD-
CN894 3708-001114 CONNECTOR-FPC/FC/PIC;30P,0.5mm,SMD-S,SN
CN895 3711-002162 CONNECTOR-HEADER;3WALL,2P,1R,1.25mm,SMD-
CT891 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
D890 0401-000101 DIODE-SWITCHING;1N4148,100V,200mA,DO-35,
DG04 0401-001054 DIODE-SWITCHING;KDS160,85V,300mA,SOD-323
GY01 AD32-92001C SENSOR;3V,-,-5to75C,-,0.66V,L33AB0
GY02 AD32-92001D SENSOR;3V,-,-5to75C,-,0.66V,L33AB1
ICG01 AD09-00019A IC-MICOM;HD6433292 V06X,80,TRAY,-,16 BIT
ICG03 1201-001193 IC-OP AMP;2112,SOP,14P,173MIL,DUAL,10000
ICG04 1201-000200 IC-OP AMP;3414,SOP,8P,173MIL,DUAL,-,PLAS
ICG05 AC14-12007X IC-LOGIC;TC4S66F,SSOP-5,5P
ICG06 AC14-12007X IC-LOGIC;TC4S66F,SSOP-5,5P
J890 3722-001308 JACK-PHONE;5P,3.6mm,AG,BLK,NO STEREO
J890 3722-001313 JACK-PHONE;3P,3.6mm,AG,BLK,NO MONO
J891 AC37-22002Q JACK-DC;12.5mm,DUAE-9811,4P,BULK,8PIN
JA891 AC37-22002Q JACK-DC;12.5mm,DUAE-9811,4P,BULK,8PIN
JA892 3722-001308 JACK-PHONE;5P,3.6mm,AG,BLK,NO STEREO
JA892 3722-001313 JACK-PHONE;3P,3.6mm,AG,BLK,NO MONO
LG01 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
LG02 2703-000403 INDUCTOR-SMD;22uH,10%,3.2x2.5x2.2mm
LG03 2703-001758 INDUCTOR-SMD;100uH,10%,3.2x2.5x2.2mm
RE890 AD59-60060E MODULE-REMOCON;DP,PNA4612M00XC,38KHz,940
RG03 2007-000583 R-CHIP;22Kohm,1%,1/16W,DA,TP,1608
RG04 2007-000583 R-CHIP;22Kohm,1%,1/16W,DA,TP,1608
RG05 2007-000583 R-CHIP;22Kohm,1%,1/16W,DA,TP,1608
RG06 2007-000583 R-CHIP;22Kohm,1%,1/16W,DA,TP,1608
RG07 2007-000583 R-CHIP;22Kohm,1%,1/16W,DA,TP,1608
RG08 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
RG09 2007-000583 R-CHIP;22Kohm,1%,1/16W,DA,TP,1608
RG10 2007-000086 R-CHIP;5.6Kohm,5%,1/16W,DA,TP,1608
RG11 2007-000107 R-CHIP;470Kohm,5%,1/16W,DA,TP,1608
RG12 2007-000107 R-CHIP;470Kohm,5%,1/16W,DA,TP,1608
RG13 2007-000107 R-CHIP;470Kohm,5%,1/16W,DA,TP,1608
RG14 2007-000107 R-CHIP;470Kohm,5%,1/16W,DA,TP,1608
ASS'Y-FUNCTION BOARD
CN471 3711-000595 CONNECTOR-HEADER;BOX,10P,1R,2mm,ANGLE,SN
CN472 3711-000906 CONNECTOR-HEADER;BOX,3P,1R,2mm,ANGLE,SN EVF
R471 2004-000971 R-METAL;470ohm,1%,1/8W,AA,TP,1.8x3.2mm
R472 2004-000413 R-METAL;18Kohm,1%,1/8W,AA,TP,1.8x3.2mm
R473 2004-000798 R-METAL;33Kohm,1%,1/8W,AA,TP,1.8
R474 2004-000798 R-METAL;33Kohm,1%,1/8W,AA,TP,1.8
R475 2004-001199 R-METAL;68Kohm,1%,1/8W,AA,TP,1.8x3.2mm
R476 2004-000971 R-METAL;470ohm,1%,1/8W,AA,TP,1.8x3.2mm
R477 2004-000413 R-METAL;18Kohm,1%,1/8W,AA,TP,1.8x3.2mm
R478 2004-000798 R-METAL;33Kohm,1%,1/8W,AA,TP,1.8
R479 2004-000798 R-METAL;33Kohm,1%,1/8W,AA,TP,1.8
R480 2004-001199 R-METAL;68Kohm,1%,1/8W,AA,TP,1.8x3.2mm
SW471 3404-001081 SWITCH-TACT;15V,20mA,130gf,6x6x4.3mm,SPS
SW472 3404-001081 SWITCH-TACT;15V,20mA,130gf,6x6x4.3mm,SPS
SW473 3404-001081 SWITCH-TACT;15V,20mA,130gf,6x6x4.3mm,SPS
SW474 3404-001081 SWITCH-TACT;15V,20mA,130gf,6x6x4.3mm,SPS
SW475 3404-001081 SWITCH-TACT;15V,20mA,130gf,6x6x4.3mm,SPS
SW476 3404-001081 SWITCH-TACT;15V,20mA,130gf,6x6x4.3mm,SPS
SW477 3404-001081 SWITCH-TACT;15V,20mA,130gf,6x6x4.3mm,SPS
SW478 3404-001081 SWITCH-TACT;15V,20mA,130gf,6x6x4.3mm,SPS
SW479 3404-001081 SWITCH-TACT;15V,20mA,130gf,6x6x4.3mm,SPS
SW480 3404-001081 SWITCH-TACT;15V,20mA,130gf,6x6x4.3mm,SPS
VR471 2101-001049 VR-ROTARY;500OHM,-,-,-
VR472 2101-001050 VR-ROTARY;50KOHM,30%,1/30W,TOP
W471 3811-000389 WIRE-NO SHEATH CU;SPCW,300V,52.4mm,1/0.5
W472 3811-000389 WIRE-NO SHEATH CU;SPCW,300V,52.4mm,1/0.5
ASS'Y-FRONT BOARD
C890 2401-002206 C-AL;47uF,20%,6.3V,GP,TP,5x7,5mm
CG01 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
CG02 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CG06 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CG07 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
CG08 2404-000139 C-TA,CHIP;10uF,20%,6.3V,-,3216,-,TP
CG09 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CG10 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
CG11 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CG12 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608,
CG15 2203-000440 C-CERAMIC,CHIP;1nF,10%,50V,X7R,TP,1608,-
CG16 2203-000189 C-CERAMIC,CHIP;100nF,+80-20%,25V,Y5V,TP,
CG17 2203-000604 C-CERAMIC,CHIP;22nF,10%,25V,X7R,TP,1608,
CG18 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,
CG19 2203-005221 C-CERAMIC,CHIP;15nF,10%,50V,X7R,TP,1608,
CG20 2203-000560 C-CERAMIC,CHIP;220nF,+80-20%,25V,Y5V,TP,
CG21 2203-005221 C-CERAMIC,CHIP;15nF,10%,50V,X7R,TP,1608,
CG22 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
CG23 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
CG24 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
CG25 2404-001039 C-TA,CHIP;47uF,20%,6.3V,GP,TP,3528,-
CG26 2203-001630 C-CERAMIC,CHIP;330nF,+80-20%,16V,Y5V,TP,
