Samsung Electronics 7-19

Electrical Parts List

Loc. No Part No Desc & Spec Remark

RG15 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608

RG16 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608

RG17 2007-001026 R-CHIP;560Kohm,5%,1/16W,DA,TP,1608

RG18 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608

RG19 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608

RG21 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608

RG22 2007-000092 R-CHIP;15Kohm,5%,1/16W,DA,TP,1608

RG23 2007-001026 R-CHIP;560Kohm,5%,1/16W,DA,TP,1608

RG24 2007-000097 R-CHIP;47Kohm,5%,1/16W,DA,TP,1608

RG25 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608

RG27 2007-000090 R-CHIP;10Kohm,5%,1/16W,DA,TP,1608

RG28 2007-000077 R-CHIP;470ohm,5%,1/16W,DA,TP,1608

RG29 2007-000781 R-CHIP;33OHM,5%,1/10W,DA,TP,2012

RG36 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608

RG37 2007-000070 R-CHIP;0ohm,5%,1/16W,DA,TP,1608

RM891 AD59-60060E MODULE-REMOCON;DP,PNA4612M00XC,38KHz,940

SW890 3409-001035 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE

SW891 3409-001036 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE

SW892 3409-001035 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE

XG01 2801-003246 CRYSTAL-SMD;10MHz,10ppm,28-ABR,12pF,70oh

ASS'Y-REAR BOARD

BT771 AD61-30197A PLATE-TERMINAL +;-,S-F RM23,T0.5,OD20.7*

BT772 AD61-30197A PLATE-TERMINAL +;-,S-F RM23,T0.5,OD20.7*

BT773 AD61-60630A SPRING-LITHUM;-,-,C5210R,H,0.25,-,-,SC-L

BT774 AD61-60629A SPRING-LITHUM +;-,-,C5210R,H,0.25,-,-,SC

CN771 3711-004242 CONNECTOR-HEADER;BOX,24P,2R,1MM,SMD-A,SN

D771 0402-001166 DIODE-RECTIFIER;RL203,200V,2.0A,DO-15,TP

JA771 AD90-10847B ASSY-DC JACK;SC-L300,-

JA772 3722-001202 JACK-PHONE;7P,3.6MM,AG,YEL,NO

PS771 3601-000418 FUSE-SMD;125V,2A,SLOW-BLOW,CERAMIC,6.1x LIGHT(O)

PS772 3601-001154 FUSE-SMD;125V,2.5A,SB,CERAMIC,2.69X6.1MM LIGHT(X)

R771 2007-000931 R-CHIP;470OHM,5%,1/10W,DA,TP,2012

R772 2007-000931 R-CHIP;470OHM,5%,1/10W,DA,TP,2012

R775 2007-000565 R-CHIP;220KOHM,5%,1/10W,DA,TP,2012

SW771 3409-001036 SWITCH-DETECTOR;3~5V,50uA~10mA,2,30gf,LE

SW772 3404-001084 SWITCH-TACT;15V,20mA,-,6X6X7mm,4

VR771 2101-001018 VR-ROTARY;50Kohm,30%,1/30W,TOP,-
