English _109
●
APPENDIX
PRODUCT SPECIFICATION
Item
Details
SDR-5200 SDR-4200
Operation System Embedded LINUX
Input Video Format HD : HD-UTP (Own format, 1080P/720P), SD : CVBS
Operation Mode Live/REC/PB/NW
Video In
Channel 16CH(4CH HD, 12CH SD) 8CH(4CH HD, 4CH SD)
Connector Type UTP(HD) x 4CH, BNC(SD) x 12CH UTP(HD) x 4CH, BNC(SD) x 4CH
Video Out
VGA NTSC : MAX 1080P (60Hz), PAL : MAX 1080P (50Hz)
HDMI NTSC : MAX 1080P (60Hz), PAL : MAX 1080P (50Hz)
Simultaneous Out VGA and HDMI
Audio In
Channel 4
Connector Type RCA
Audio Out
Channel 1
Connector Type RCA
Compression
Video H.264
Audio G.711
Codec Type H/W
Dual Codec O
Live
Resolution 1080P/720P/960H
Split Mode
1/4/8/9/13/16/PIP 1/4/8/9/13/PIP
Recording
Resolution & Frame
Rate
HD : 1080p(NTSC:MAX 120fps /
PAL:MAX 100fps),
720p(NTSC:MAX 120fps /
PAL:MAX 100fps)
SD : 960H (NTSC:MAX 360fps /
PAL:MAX 300fps)
HD : 1080p(NTSC:MAX 120fps /
PAL:MAX 100fps),
720p(NTSC:MAX 120fps /
PAL:MAX 100fps)
SD : 960H (NTSC:MAX 120fps /
PAL:MAX 100fps)
Quality Level 8Level(LV1~LV8)
appendix

Samsung SDC-7340BC Specifications

General

Camera Type	Dome
Lens Type	Fixed
Field of View	90°
Night Vision	Yes
Connectivity	Wired
IR Range	20 m
Weatherproof	IP66
Signal System	PAL/NTSC
Synchronization	Internal
Lens	3.6mm
S/N Ratio	More than 50dB
Power Supply	DC 12V
Power Consumption	3.5W
Minimum Illumination	0.01 Lux
Electronic Shutter Speed	1/50 (1/60) to 1/100, 000 sec
