Samsung SGH-E390 - Parts List

SAMSUNG Proprietary-Contents may change without notice
Exploded View/Disassembly&Assembly Instructions
5-2
This Document can not be used without Samsung's authorization
5-2. Cellular phone Parts list
Design LOC Description Sec Code
QAN02 INTENNA-SGHE390 GH42-01041A
QAN05 ASSY RUBBER-ANTENNA GH98-03075A
QBA00 PMO-COVER BATT GH72-33910A
QBA01 INNER BATTERY PACK-800MAH,BLK, GH43-02472A
QCA01 UNIT-SGHE390 CAMERA MODULE GH59-03694A
QCR12 SCREW-MACHINE 6001-001530
QCR12 SCREW-MACHINE 6001-001530
QCR12 SCREW-MACHINE 6001-001530
QFU01 ASSY CASE-UPPER SLIDE GH98-02121A
QKP01 ASSY KEYPAD-MAIN(XET/BLK) GH98-02126A
QKP02 ASSY KEYPAD-SUB(XET/BLK) GH98-02125A
QLC01 LCD-LCD MODULE GH07-01001A
QME02 UNIT-METAL DOME SUB GH59-03681A
QMI03 RMO-RUBBER MIC GH73-07941A
QMP01 PBA MAIN-SGHE390 GH92-03193A
QMP02 PBA SUB-SGHE390 GH92-03199A
QMW02 PCT-COVER WINDOW MAIN GH72-33917A
QPC01 MEA-SLIDER FPCB KIT GH97-06896A
QSC05 RMO-RUBBER SCREW CAP LOWER GH73-07944A
QSP02 UNIT-MODULE SPEAKER GH59-03695A
QME01 UNIT-KEY PBA GH59-03642A
QMI01 AS-MIC SVC GH81-06085A
QRE01 ASSY CASE-REAR GH98-02127A
QIF01 PMO-COVER IF GH72-33908A
QSD01 PMO-COVER MICRO SD GH72-33909A
QFL01 ASSY CASE-FRONT SLIDE LOWER GH98-02123A
QFL02 ASSY CASE-SLIDE LOWER GH98-02122A
QFR01 ASSY CASE-FRONT GH98-02124A
QCK01 PMO-CAMERA KEY GH72-33903A
QVO01 PMO-VOLUME KEY GH72-33904A
QSC21 ASSY RUBBER-DAMPER L GH98-03030A
QSC22 ASSY RUBBER-DAMPER R GH98-03031A
QHI03 ASSY HINGE-SLIDE GH98-03025A
