Flow Chart of Troubleshooting
9-18
9-10. Key Back Light
U302 pin 1 = H ?
Check the U302 related to "KEY_LED_ON"
signal
END
No
Yes
Yes
Main Key LED does not work
U302 pin 4 = H ?
No
Replace U302
Yes
