Samsung SGH-E390 - Receiver Part

SAMSUNG Proprietary-Contents may change without notice
This Document can not be used without Samsung's authorization
Flow Chart of Troubleshooting
9-14
9-8. Receiver Part
Check the power of analog
switch(U822, U823).
Is L821, L822 = 3.8V?
Resolder L821, L822
END
No
Yes
Yes
Receiver does not work
Check the 'AUDIO_SEL' Pin
of U822, U823.
Is Pin 4, 9 "L"?
Check UCP200
No
Yes
Is Receiver working?
Replace the Receiver
No
Yes
Check the connection
status of Receiver
No
Resolder the receiver
Yes
