Samsung SGH-E390 - Power On Troubleshooting

SAMSUNG Proprietary-Contents may change without notice
9. Flow Chart of Troubleshooting
This Document can not be used without Samsung's authorization
9-1
9-1. Power On
Check the Battery Voltage
is more than 3.4V
' Power On ' does not work
Charge the Battery
END
No
Yes
C406(VINT) = 2.7V?
Check the PMU related to VINT
No
Yes
Check the Clock at
R401=32KHZ
Resolder OSC400
No
Yes
C425(+VDD_IO_LOW) &
C424(+VDD_IO_HIGH) = "H"?
Check the related circuit
No
Yes
TA516(+VDD_GSM_CORE)
= 1.875V?
Check the +VDD_GSM_CORE circuit
No
Yes
Check for the clock at C129
=26MHz
Check the clock generation circuit
(related to OSC100)
No
Yes
Check the initial operation
Yes
Yes
