Flow Chart of Troubleshooting
9-6
9-4. Sim Part
CN400 pin 11,14 = "H"?
After Power ON,
Check SIMCLK Signal on
pin15 of CN400 in a few
second
After SIM card insert,
CN400 pin 13 = "H(SIM_RST)"?
Phone can't access SIM Card
Check the sim charge pump
Check the SIM Card
END
No
Yes
Yes
Yes
No
Check the Clock
Yes
No
Replace PBA
Yes
To Next Page
